2-2
M32000D3FP User's Manual
CPU
2.1 CPU register
The M32R CPU has 16 general-purpose registers, 5 control registers, an accumulator and a program
counter. The accumulator is of 64-bit width. The registers and program counter are of 32-bit width.
2.2 General-purpose registers
The 16 general-purpose registers (R0 - R15) are of 32-bit width and are used to retain data and base
addresses. R14 is used as the link register and R15 as the stack pointer (SPI or SPU). The link register
is used to store the return address when executing a subroutine call instruction. The interrupt stack pointer
(SPI) and the user stack pointer (SPU) are alternatively represented by R15 depending on the value of the
stack mode bit (SM) in the processor status word register (PSW).
Fig. 2.2.1 General-purpose registers
R0
R1
R2
R3
R4
R5
R6
R7
31
0
R8
R9
R10
R11
R12
R13
R14 (link register)
R15 (stack pointer)
31
0
(see note)
Note: The interrupt stack pointer (SPI) and the user stack pointer (SPU) are alternatively
represented by R15 depending on the value of the stack mode bit (SM) in the PSW.
