16
AMD-K5 Processor Data Sheet
18522F/0—Jan1997
PRELIMINARY INFORMATION
BF1–BF0 (Model 1
and Model 2)
Bus Frequency
For the AMD-K5 model 1 and model 2 processors, the BF1 and
BF0 signals determine the internal operating speed of the pro-
cessor. The frequency of the CLK signal is multiplied inter-
nally by a ratio determined by the states of the BF1 and BF0
signals during RESET. The processor speed multiplier is deter-
mined as shown below:
Input
BOFF
Backoff
The processor will transition to a bus hold state and float the
associated signals on the clock that BOFF is sampled as
asserted. An alternate master may drive the bus signals on the
clock after BOFF is sampled asserted. When BOFF is negated,
the processor will restart any bus cycle from the beginning.
Burst cycles interrupted by BOFF will restart from the begin-
ning of the burst cycle. BOFF takes priority over BRDY. If
BRDY is sampled asserted in the same cycle as BOFF, the cycle
will be restarted.
(
See Switching Characteristics
t
22
and
t
23
.)
Input
BRDY
Burst Ready
BRDY is sampled on the second and following clocks of a bus
cycle to indicate completion of a data transfer cycle. BRDY is
ignored at the end of the first clock of a bus cycle and when the
bus is in an idle state. The data bus is sampled when BRDY is
asserted. Up to four assertions of BRDY are needed to com-
plete the bus cycle. (See Switching Characteristics
t
20
and
t
21
.)
Input
BRDYC
Burst Ready Copy
BRDYC is functionally identical to BRDY. These signals are
connected internally by an OR gate. BRDYC is typically used
by level two cache. At the falling edge of RESET, the states of
BRDYC and BUSCHK
control the drive strength on the A21–
A3 (not including A31–A22), ADS, HITM, and W/R signals. The
drive strength is weak for all states of BRDYC and BUSCHK
except when BRDYC and BUSCHK are both Low, in which case
Input
BF1 Pin
0
0
1
1
BF0 Pin
0
1
0
1
Internal Clock Multiplier
1.75
Reserved
1.5
1.5
