MOTOROLA
MC68HC916X1
96
MC68HC916X1TS/D
TIC[1:3] — Input Capture Registers 1–3
$YFF90E, $YFF910, $YFF912
The input capture registers are 16-bit read-only registers which are used to latch the value of TCNT
when a specified transition is detected on the corresponding input capture pin. They are reset to $FFFF.
TOC[1:4] — Output Compare Registers 1–4
$YFF914, $YFF916, $YFF918, $YFF91A
The output compare registers are 16-bit read/write registers which can be used as output waveform
controls or as elapsed time indicators. For output compare functions, they are written to a desired match
value and compared against TCNT to control specified pin actions. They are reset to $FFFF.
TI4/O5 — Input Capture 4/Output Compare 5 Register
$YFF91C
This register serves either as input capture register 4 or output compare register 5, depending on the
state of I4/O5 in PACTL.
TCTL1 determines output compare mode and output logic level. TCTL2 determines the type of in-
put capture to be performed.
OM/OL[5:2] — Output Compare Mode Bits and Output Compare Level Bits
Each pair of bits specifies an action to be taken when output comparison is successful. Refer to Table
EDG[4:1]B/A — Input Capture Edge Control Bits
Each pair of bits configures input sensing logic for the corresponding input capture. Refer to Table 49.
TCTL1/TCTL2 — Timer Control Registers 1–2
$YFF91E
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
OM5
OL5
OM4
OL4
OM3
OL3
OM2
OL2 EDG4B EDG4A EDG3B EDG3A EDG2B EDG2A EDG1B EDG1A
RESET:
0
Table 48 OM/OL[5:2] Bit Field Effects
OM/OL[5:2]
Action Taken
00
Timer disconnected from output logic
01
Toggle OCx output line
10
Clear OCx output line to 0
11
Set OCx output line to 1
Table 49 EDG[4:1]B/A Bit Field Effects
EDG[4:1]B/A
Configuration
00
Capture disabled
01
Capture on rising edge only
10
Capture on falling edge only
11
Capture on any (rising or falling) edge
TMSK1/TMSK2 — Timer Interrupt Mask Registers 1–2
$YFF920
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
I4/O5I
OCI[4:1]
ICI[3:1]
TOI
0
PAOVI PAII CPROUT
CPR[2:0]
RESET:
0
F
re
e
sc
a
le
S
e
m
ic
o
n
d
u
c
to
r,
I
Freescale Semiconductor, Inc.
For More Information On This Product,
Go to: www.freescale.com
n
c
..
.
