Intel
a
Celeron
Processor Mobile Module MMC-2
at 400 MHz, 366 MHz, 333 MHz, and 300 MHz
39
4.8
Active Thermal Feedback
Table 24 identifies the address allocated for the SMBus
thermal sensor used on the Celeron processor mobile
module MMC-2.
Table 24. Thermal Sensor SMBus Address Table
Function
SMBus Address
Thermal Sensor
1001 110
NOTE:
The thermal sensor used is compliant with SMBus addressing. Please refer to the
Pentium II processor Thermal Sensor Interface
Specification
.
4.9
Thermal Sensor Configuration Register
The configuration register of the thermal sensor controls the
operating mode (Auto Convert vs. Standby) of the device.
Since the processor temperature varies dynamically during
normal operation, Auto Convert mode should be used
exclusively to monitor processor temperature. Table 25
shows the format of the configuration register. If the
RUN/STOP bit is low, then the thermal sensor enters Auto
Convert mode. If the RUN/STOP bit is set high, then the
thermal sensor immediately stops converting and enters the
Standby mode. The thermal sensor will still perform
temperature conversions in Standby mode when it receives
a one-shot command. However, the result of a one-shot
command during Auto Convert mode is not guaranteed. Intel
does not recommend using the one-shot command to
monitor temperature when the processor is active, only Auto
Convert mode should be used. Refer to the
Mobile Pentium
II Processor and Pentium
II Processor Mobile Module
Thermal Sensor Interface Specifications
, Rev.1.0.
Table 25. Thermal Sensor Configuration Register
Reset State
Bit
Name
Function
7 MSB
MASK
0
Masks SMBALERT# when high.
6
RUN/STOP
0
Standby mode control bit. If low, the device enters auto-
convert mode. If high, the device immediately stops
converting, and enters standby mode where the one-shot
command can be performed.
5 – 0
RFU
0
Reserved for future use.
NOTE:
All RFU bits should be written as “0” and read as “don’t care” for programming purposes.
5.0
MECHANICAL SPECIFICATION
This section provides the physical dimensions for the
Celeron processor mobile module MMC-2.
5.1
Module Dimensions
Figure 10 shows the board dimensions and the connector
orientation.
