Intel
a
Celeron
Processor Mobile Module MMC-2
at 400 MHz, 366 MHz, 333 MHz, and 300 MHz
21
3.3
Pin and Pad Assignments
The MMC-2 connector has 400 pins, a 1.27-millimeter pitch,
and has a BGA style surface mount. Refer to Section 5.1.4,
”Height Requirements”
for connector size information.
Figure 2 shows the pad assignments of the MMC-2
connector.
400-Pin Connector
OEM Pad Assignments
(Viewed from Secondary Side)
K
A
1
40
Figure 2. 400-Pin Connector Footprint Pad Numbers
