Intel
a
Celeron
Processor Mobile Module MMC-2
at 400 MHz, 366 MHz, 333 MHz, and 300 MHz
33
Table 23 details the bulk capacitance requirements for the
system electronics.
Table 23. Capacitance Requirement per Power Plane
Capacitance Requirements
Power Plane
ESR
Ripple Current
Rating
V_DC
100 uf, 0.1 uf, 0.01 uf
1
20 m
1A-3.5A
3
20% tolerance at 35V
V_5
100 uf, 0.1 uf, 0.01 uf
1
100 m
1A
20% tolerance at 10V
V_3
470 uf, 0.1 uf, 0.01 uf
1
100 m
1A
20% tolerance at 6V
V_3S
100 uf, 0.1 uf, 0.01 uf
1
100 m
N/A
20% tolerance at 6V
VCC_AGP
22 uf, 0.1 uf, 0.01 uf
1
100 m
1A
20% tolerance at 6V
V_CPUPU
2.2 uf, 8200 pf
1
N/A
N/A
20% tolerance at 6V
V_CLK2
10 uf, 8200 pf
2
N/A
N/A
20% tolerance at 6V
NOTES:
1.
2.
3.
Placement of above capacitance requirements should be located near the connector.
V_CLK filtering should be located next to the system clock synthesizer.
Ripple current specification depends on V_DC input. For 5.0-V V_DC, a 3.5A device is required. For V_DC at 18V or higher,
1A is sufficient.
