Intel
a
Celeron
Processor Mobile Module MMC-2
at 400 MHz, 366 MHz, 333 MHz, and 300 MHz
29
4.6.2.1
PSB Clock Signal Quality Specifications
and Measurement Guidelines
Table 19 describes the signal quality specifications at the
processor core for the PSB clock (BCLK) signal.
Figure 4 describes the signal quality waveform for the PSB
clock at the processor core pins.
Table 19. BCLK Signal Quality Specifications at the Processor Core
1,5
T#
Parameter
Min
Nom
Max
Unit
V1:
V2:
V3:
BCLK V
IL
2
BCLK V
IH
2
V
IN
Absolute Voltage Range
3
Rising Edge Ringback
4
Falling Edge Ringback
4
BCLK rising/falling slew rate
0.7
V
V
V
1.8
–0.8
3.5
V4:
V5:
1.8
V
V
0.7
4
0.8
V/ns
NOTES:
1.
2.
3.
4.
Unless otherwise noted, all specifications in this table apply Intel mobile modules.
BCLK must rise/fall monotonically between V
IL,BCLK
and V
IH, BCLK.
This is the processor PSB clock overshoot and undershoot specification for a 66-MHz PSB operation.
The rising and falling edge ringback voltage specified is the minimum (rising) or maximum (falling) absolute voltage
the BCLK signal can dip back to after passing the V
IH
(rising) or V
IL
(falling) voltage limits.
For proper signal termination, refer to the Clocking Guidelines in the
Mobile Pentium
a
II Processor / 440BX AGPset
Advanced Platform Recommend Design and Debug Practices.
5.
V2
V1
V3
V3
T3
V5
V4
T6
T4
T5
Figure 4. BCLK, TCK, and PICCLK Generic Clock Waveform at the Processor Core Pins
4.7
Voltage Regulator
The DC voltage regulator (DC/DC converter) provides the
appropriate core voltage, the I/O ring voltage, and the
sideband signal pullup voltage for the Celeron processor
mobile module MMC-2. The voltage range is 5 volts to 21
volts.
4.7.1
Voltage Regulator Efficiency
Table 18 lists the voltage regulator efficiencies.
