KM4132G512
CMOS SGRAM
- 11
Rev. 2.2 (June 1998)
1. Apply power and start clock, Attempt to maintain CKE= "H", DQM= "H" and the other pins are NOP condition at the inputs.
2. Maintain stable power, stable clock and NOP input condition for a minimum of 200us.
3. Issue precharge commands for all banks of the devices.
4. Issue 2 or more auto-refresh commands.
5. Issue a mode register set command to initialize the mode register.
cf.) Sequence of 4 & 5 may be changed.
The device is now ready for normal operation.
Note
: 1. RFU(Reserved for Future Use) should stay "0" during MRS cycle.
2. If A
9
is high during MRS cycle, "Burst Read Single Bit Write" function will be enabled.
3. The full column burst(256bit) is available only at Sequential mode of burst type.
4. If LC and LM both high(1), data of mask and color register will be unknown.
Register Programmed with MRS
(Note 1) (Note 2)
Address
A
10
A
9
A
8
A
7
A
6
A
5
A
4
A
3
A
2
A
1
A
0
Function
RFU
W.B.L
TM
CAS Latency
BT
Burst Length
(Note 3)
Test Mode
CAS Latency
Burst Type
Burst Length
A
8
A
7
Type
A
6
A
5
A
4
Latency
A
3
Type
A
2
A
1
A
0
BT=0
BT=1
0
0
Mode Register Set
0
0
0
Reserved
0
Sequential
0
0
0
1
Reserved
0
1
Vendor
Use
Only
0
0
1
-
1
Interleave
0
0
1
2
Reserved
1
0
0
1
0
2
0
1
0
4
4
1
1
0
1
1
3
0
1
1
8
8
Write Burst Length
1
0
0
Reserved
1
0
0
Reserved
Reserved
A
9
Length
1
0
1
Reserved
1
0
1
Reserved
Reserved
0
Burst
1
1
0
Reserved
1
1
0
Reserved
Reserved
1
Single Bit
1
1
1
Reserved
1
1
1
256(Full)
Reserved
Special Mode Register Programmed with SMRS
Address
A
10
A
9
A
8
A
7
A
6
A
5
A
4
A
3
A
2
A
1
A
0
Function
X
LC
LM
X
(Note 4)
Load Color
Load Mask
A
6
Function
A
5
Function
0
Disable
0
Disable
1
Enable
1
Enable
MODE REGISTER FIELD TABLE TO PROGRAM MODES
POWER UP SEQUENCE
