9397 750 14223
Koninklijke Philips Electronics N.V. 2005. All rights reserved.
Product data sheet
Rev. 01 — 14 July 2005
68 of 98
Philips Semiconductors
ISP1562
USB PCI Host Controller
[1]
The reserved bits should always be written with the reset value.
Table 94:
Address: Value read from func2 of address 10h + 24h
Bit
31
Symbol
Reset
0
Access
R/W
Bit
23
Symbol
Reset
0
Access
R/W
Bit
15
Symbol
ASS
Reset
0
Access
R
Bit
7
Symbol
reserved
[1]
USBSTS - USB Status register bit allocation
30
29
28
27
26
25
24
reserved
[1]
0
0
0
0
0
0
0
R/W
22
R/W
21
R/W
20
R/W
19
R/W
18
R/W
17
R/W
16
reserved
[1]
0
0
0
0
0
0
0
R/W
14
PSSTAT
0
R
6
R/W
13
RECL
0
R
5
IAA
R/W
12
HCH
1
R
4
HSE
R/W
11
R/W
10
R/W
9
R/W
8
reserved
[1]
0
0
0
0
R/W
3
FLR
R/W
2
PCD
R/W
1
USB
ERRINT
0
R/W
R/W
0
USBINT
Reset
Access
0
0
0
R
0
0
0
0
R/W
R/W
R/W
R/W
R/W
R/W
Table 95:
Address: Value read from func2 of address 10h + 24h
Bit
Symbol
Description
31 to 16
reserved
-
15
ASS
Asynchronous Schedule Status
: Default = 0. The bit reports the
current real status of the asynchronous schedule. If this bit is logic 0,
the status of the asynchronous schedule is disabled. If this bit is logic 1,
the status of the asynchronous schedule is enabled. The Host
Controller is not required to immediately disable or enable the
asynchronous schedule when software changes ASE (bit 5 in the
USBCMD register). When this bit and the ASE bit have the same value,
the asynchronous schedule is either enabled (1) or disabled (0).
14
PSSTAT
Periodic Schedule Status
: Default = 0. This bit reports the current
status of the periodic schedule. If this bit is logic 0, the status of the
periodic schedule is disabled. If this bit is logic 1, the status of the
periodic schedule is enabled. The Host Controller is not required to
immediately disable or enable the periodic schedule when software
changes PSE (bit 4) in the USBCMD register. When this bit and the
PSE bit have the same value, the periodic schedule is either enabled (1)
or disabled (0).
13
RECL
Reclamation
: Default = 0. This is a read-only status bit that is used to
detect an empty asynchronous schedule.
12
HCH
HCHalted
: Default = 1. This bit is logic 0 when RS (bit 0) in the
USBCMD register is logic 1. The Host Controller sets this bit to logic 1
after it has stopped executing because the RS bit is set to logic 0, either
by software or by the Host Controller hardware. For example, on an
internal error.
USBSTS - USB Status register bit description
