39
μ
PD784031Y
(1) 3-wire serial I/O mode
This mode is to communicate with devices having the conventional clocked serial interface.
Basically, communication is established in this mode with three lines: one serial clock (SCK0) and two serial data
(SI0 and SO0) lines.
Generally, a handshake line is necessary to check the communication status.
(2) 2-wire serial I/O mode
This mode is to transfer 8-bit data by using two lines: serial clock (SCL) and serial data bus (SDA).
Generally, a handshake line is necessary to check the communication status.
(3) I
2
C (Inter IC) bus mode
This mode is to communicate with devices conforming to the I
2
C bus format.
This mode is to transfer 8-bit data with two or more devices by using two lines: serial clock (SCL) and serial data
bus (SDA).
During transfer, a “start condition”, “data”, and “stop condition” can be output onto the serial data bus. During
reception, these data can be automatically detected by hardware.
7.9 Edge Detection Function
The interrupt input pins (NMI and INTP0 through INTP5) are used not only to input interrupt requests but also to input
trigger signals to the internal hardware units. Because these pins operate at an edge of the input signal, they have a function
to detect an edge. Moreover, a noise reduction circuit is also provided to prevent erroneous detection due to noise.
Pin Name
Detectable Edge
Noise Reduction
NMI
Either of rising or falling edge
By analog delay
INTP0 to INTP3
Either or both of rising and falling edges
By clock sampling
Note
INTP4, INTP5
By analog delay
Note
INTP0 can select a sampling clock.
