7.4 Timer/Counter
Three units of timers/counters and one unit of timer are provided.
Because a total of seven interrupt requests are supported, these timers/counters and timer can be used as seven units
of timers/counters.
Table 7-2. Operations of Timers/Counters
Name
Timer/Counter 0
Timer/Counter 1
Timer/Counter 2
Timer 3
Item
Count width
8 bits
–
√
√
√
16 bits
√
√
√
√
Interval timer
2ch
2ch
2ch
1ch
External event counter
√
√
√
–
One-shot timer
–
–
√
–
Function
Timer output
2ch
–
2ch
–
Toggle output
√
–
√
–
PWM/PPG output
√
–
√
–
One-shot pulse output
Note
√
–
–
–
Real-time output
–
√
–
–
Pulse width measurement
1 input
1 input
2 inputs
–
Number of interrupt requests
2
2
2
1
Note
The one-shot pulse output function makes a pulse output level active by software and inactive by hardware (interrupt
request signal).
This function is different in nature from the one-shot timer function of timer/counter 2.
Operation
mode
