1996
DATA SHEET
The mark
#
shows major revised points.
MOS INTEGRATED CIRCUIT
μ
PD784035Y,784036Y,784037Y,784038Y
16-/8-BIT SINGLE-CHIP MICROCONTROLLERS
DESCRIPTION
The
μ
PD784038Y is based on the
μ
PD784038 with an I
2
C bus control function added, and is ideal for audio-visual
applications.
One-time PROM and EPROM versions, such as the
μ
PD78P4038Y, that can operate in the same voltage range
as mask ROM versions, and various development tools are provided.
The functions are explained in detail in the following User’s Manual. Be sure to read this manual when designing
your system.
μ
PD784038, 784038Y Subseries User’s Manual - Hardware: U11316E
78K/IV Series User’s Manual - Instruction:
U10905E
Document No. U10741EJ1V0DS00 (1st edition)
Date Published July 1997 N
Printed in Japan
FEATURES
78K/IV Series
Pin-compatible with
μ
PD78234 Subseries,
μ
PD784026 Subseries, and
μ
PD784038
Subseries
Higher internal memory capacity than
μ
PD78234
Subseries and
μ
PD784026 Subseries
Minimum instruction execution time: 125 ns
(@ 32-MHz operation)
I/O ports: 64
Serial interface: 3 channels
UART/IOE (3-wire serial I/O): 2 channels
CSI (3-wire serial I/O, 2-wire serial I/O, I
2
C bus):
1 channel
Timer/counter 16-bit timer/counter
×
3 units 16-bit
timer
×
1 unit
PWM output: 2 outputs
Standby function
HALT/STOP/IDLE mode
Clock division function
Watchdog timer: 1 channel
Clock output function
Selectable from f
CLK
, f
CLK
/2, f
CLK
/4, f
CLK
/8, and
f
CLK
/16
A/D converter: 8-bit resolution
×
8 channels
D/A converter: 8-bit resolution
×
2 channels
Supply voltage: V
DD
= 2.7 to 5.5 V
APPLICATION FIELDS
Cellular phones, cordless phones, audio-visual systems, etc.
Unless contextually excluded, references in this document to the
μ
PD784038Y mean
μ
PD784035Y,
μ
PD784036Y,
and
μ
PD784037Y.
The information in this document is subject to change without notice.
