12
μ
PD784031Y
5.2 Non-port Pins
Pin Name
I/O
Alternate Function
Function
TO0 to TO3
Output
P34 to P37
Timer output
CI
Input
P23/INTP2
Count clock input to timer/counter 2
RxD
Input
P30/SI1
Serial data input (UART0)
RxD2
P13/SI2
Serial data input (UART2)
TxD
Output
P31/SO1
Serial data output (UART0)
TxD2
P14/SO2
Serial data output (UART2)
ASCK
Input
P25/INTP4/SCK1
Baud rate clock input (UART0)
ASCK2
P12/SCK2
Baud rate clock input (UART2)
SDA
I/O
P33/SO0
Serial data input/output (2-wire serial I/O, I
2
C bus)
SI0
Input
P27
Serial data input (3-wire serial I/O0)
SI1
P30/RxD
Serial data input (3-wire serial I/O1)
SI2
P13/RxD2
Serial data input (3-wire serial I/O2)
SO0
Output
P33/SDA
Serial data output (3-wire serial I/O0)
SO1
P31/TxD
Serial data output (3-wire serial I/O1)
SO2
P14/TxD2
Serial data output (3-wire serial I/O2)
SCK0
I/O
P32/SCL
Serial clock input/output (3-wire serial I/O0)
SCK1
P25/INTP4/ASCK
Serial clock input/output (3-wire serial I/O1)
SCK2
P12/ASCK2
Serial clock input/output (3-wire serial I/O2)
SCL
P32/SCK0
Serial clock input/output (2-wire serial I/O, I
2
C bus)
NMI
Input
P20
External interrupt requests
–
INTP0
P21
Count clock input to timer/counter 1
Capture trigger signal of CR11 or CR12
INTP1
P22
Count clock input to timer/counter 2
Capture trigger signal of CR22
INTP2
P23/CI
Count clock input to timer/counter 2
Capture trigger signal of CR21
INTP3
P24
Count clock input to timer/counter 0
Capture trigger signal of CR02
INTP4
P25/ASCK/SCK1
–
INTP5
P26
Conversion start trigger input to A/D converter
AD0 to AD7
I/O
–
Time-division address/data bus (for external memory connection)
A8 to A15
Output
–
Higher address bus (for external memory connection)
A16 to A19
Output
P60 to P63
Higher address when address is extended (for external memory connection)
RD
Output
–
Read strobe to external memory
WR
Output
–
Write strobe to external memory
WAIT
Input
P66/HLDRQ
Wait insertion
REFRQ
Output
P67/HLDAK
Refresh pulse output to external pseudo static memory
HLDRQ
Input
P66/WAIT
Bus hold request input
HLDAK
Output
P67/REFRQ
Bus hold acknowledge output
ASTB
Output
–
Latch timing output of time-division address (A0 through A7)
(when accessing external memory)
