11
μ
PD784031Y
5. PIN FUNCTION
5.1 Port Pins
Pin Name
I/O
Alternate Function
Function
P00 to P07
I/O
–
P10
I/O
PWM0
P11
PWM1
P12
ASCK2/SCK2
P13
RxD2/SI2
P14
TxD2/SO2
P15 to P17
–
P20
Input
NMI
P21
INTP0
P22
INTP1
P23
INTP2/CI
P24
INTP3
P25
INTP4/ASCK/SCK1
P26
INTP5
P27
SI0
P30
I/O
RxD/S1
P31
TxD/SO1
P32
SCK0/SCL
P33
SO0/SDA
P34 to P37
TO0 to TO3
P60 to P63
I/O
A16 to A19
P66
WAIT/HLDRQ
P67
REFRQ/HLDAK
P70 to P77
I/O
AN10 to AN17
Port 1 (P1):
8-bit I/O port
Can be set in input or output mode bitwise.
Pins set in input mode can be connected to internal pull-up
resistors by software.
Can drive LEDs.
Port 2 (P2):
8-bit input port
P20 cannot be used as general-purpose port pin (non-maskable
interrupt). However, its input level can be checked by interrupt
routine.
P22 through P27 can be connected to internal pull-up resistors
by software in 6-bit units.
P25/INTP4/ASCK/SCK1 pin can operate as SCK1 output pin if
so specified by CSIM1.
Port 3 (P3):
8-bit I/O port
Can be set in input or output mode bitwise.
Pins set in input mode can be connected to internal pull-up
resistors by software.
Port 6 (P6):
P60 through P63 is dedicated ports for output.
P66 and P67 can be set in input or output mode bitwise.
Pins set in input mode can be connected to internal pull-up
resistors by software.
Port 0 (P0):
8-bit I/O port
Can be used as real-time output port (4 bits x 2).
Can be set in input or output mode bitwise.
Pins set in input mode can be connected to internal pull-up
resistors by software.
Can drive transistor.
Port 7 (P7):
8-bit I/O port
Can be set in input or output mode bitwise.
