| 型號： | SSTE32882HLBBKG |
| 廠商： | INTEGRATED DEVICE TECHNOLOGY INC |
| 元件分類： | 時鐘及定時 |
| 英文描述： | SSTE SERIES, PLL BASED CLOCK DRIVER, 4 TRUE OUTPUT(S), 0 INVERTED OUTPUT(S), PBGA176 |
| 封裝： | 8 X 13.50 MM, 0.65 MM PITCH, GREEN, MO-246F, CABGA-176 |
| 文件頁數： | 12/69頁 |
| 文件大小： | 1263K |
| 代理商： | SSTE32882HLBBKG |
第1頁第2頁第3頁第4頁第5頁第6頁第7頁第8頁第9頁第10頁第11頁當前第12頁第13頁第14頁第15頁第16頁第17頁第18頁第19頁第20頁第21頁第22頁第23頁第24頁第25頁第26頁第27頁第28頁第29頁第30頁第31頁第32頁第33頁第34頁第35頁第36頁第37頁第38頁第39頁第40頁第41頁第42頁第43頁第44頁第45頁第46頁第47頁第48頁第49頁第50頁第51頁第52頁第53頁第54頁第55頁第56頁第57頁第58頁第59頁第60頁第61頁第62頁第63頁第64頁第65頁第66頁第67頁第68頁第69頁
1.25V/1.35V/1.5V REGISTERING CLOCK DRIVER WITH PARITY TEST AND QUAD CHIP SELECT
2
SSTE32882KA1
7314/5
CONFIDENTIAL - THE INFORMATION IN THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE
SSTE32882KA1
1.25V/1.35V/1.5V REGISTERING CLOCK DRIVER WITH PARITY TEST AND QUAD CHIP SELECT
COMMERCIAL TEMPERATURE RANGE
Features
Pinout optimizes DDR3 RDIMM PCB layout
DDR3-800/1066/1333/1600/1866/2133 rate
1-to-2 Register Outputs and 1-to-4 Clock Pair Outputs support stacked DDR3 RDIMMs
Phase Lock Loop clock driver for buffering one differential clock pair (CK and CK) and distributing to four differential
outputs
Supports LVCMOS switching levels on the RESET and MIRROR inputs
Checks priority on DIMM-independent data inputs
Supports dynamic 1T/3T timing transaction and output inversion feature for improved timing performance during normal
operations and MRS command pass-through
Supports CKE Power Down operation modes
Supports Quad Chip Select operation features
RESET input disables differential input recievers, resets all registers, and disables all output drivers except ERROUT and
QnCKEn
Provides access to internal control words for configuring the device features and adapting in different RDIMM and system
applications
Latch-up performance exceeds 100mA
ESD > 2000V per MIL-STD883, Method 3015; ESD > 200V using machine model (c = 200pF, R = 0)
Available in 176 Ball Grid Array package
