Universal Serial Bus
Specifications in this manual are tentative and subject to change
Rev. E
MITSUBISHI MICROCOMPUTERS
M30245 Group
SINGLE-CHIP 16-BIT CMOS MICROCOMPUTER
78
The CPU writes a “1” to the CLR_OUT_BUF_RDY bit after a data set has been unloaded from the buffer
by the CPU (updates the OUT_BUF_STS1 & OUT_BUF_STS0 flags).
If the buffer has one more data set in it, the buffer status flags transition from 112 to 102 .
If the buffer has no more data set in it, the buffer status flags transition from 102 to 002 .
AUTO_CLR is enabled and continuous transfer mode disabled:
Single Buffer Mode:
The USB FCU updates the corresponding EPx OUT CSR’s OUT_BUF_STS1 & OUT_BUF_STS0 flags
from 002 to 112 after it has successfully received a data packet from the host.
The USB FCU updates the OUT_BUF_STS1 & OUT_BUF_STS0 flags from 112 to 002 automatically
when the data packet has been unloaded from the buffer by the CPU without the CPU writing a “1” to the
CLR_OUT_BUF_RDY bit.
Double Buffer Mode:
The USB FCU updates the corresponding EPx OUT CSR’s OUT_BUF_STS1 & OUT_BUF_STS0 flags
after it has successfully received a data packet from the host.
If the buffer has only one data packet, the buffer status flags transition from 002 to 102 .
If the buffer has two data packets, the buffer status flags transition from 102 to 112 .
The USB FCU updates the OUT_BUF_STS1 & OUT_BUF_STS0 flags automatically when a data packet
has been unloaded from the buffer by the CPU without the CPU writing a “1” to the CLR_OUT_BUF_RDY
bit.
If the buffer has one more data packet in it, the buffer status flags transition from 112 to 102 .
AUTO_CLR is enable and continuous transfer mode enabled:
Single Buffer Mode:
The USB FCU updates the corresponding EPx OUT CSR’s OUT_BUF_STS1 & OUT_BUF_STS0 flags
from 002 to 112 after it has successfully received a data set equal to its buffer size or a short packet from
the host.
The USB FCU updates the OUT_BUF_STS1 & OUT_BUF_STS0 flags from 112 to 002 automatically
when the data set has been unloaded from the buffer by the CPU without the CPU writing a “1” to the
CLR_OUT_BUF_RDY bit.
Double Buffer Mode:
The USB FCU updates the corresponding EPx OUT CSR’s OUT_BUF_STS1 & OUT_BUF_STS0 flags
after it has successfully received a data set equal to its buffer size or a short packet from the host.
If the buffer has only one data set, the buffer status flags transition from 002 to 102 .
If the buffer has two data sets, the buffer status flags transition from 102 to 112 .
The USB FCU updates the OUT_BUF_STS1 & OUT_BUF_STS0 flags automatically when a data set has
been unloaded from the buffer by the CPU without the CPU writing a “1” to the CLR_OUT_BUF_RDY bit.
If the buffer has one more data set in it, the buffer status flags transition from 112 to 102.
If the buffer has no more data set in it, the buffer status flags transition from 102 to 002.
