參數資料
型號： STPCC0390BTC3
廠商： STMICROELECTRONICS
元件分類： 外設及接口
英文描述： MULTIFUNCTION PERIPHERAL, PBGA388
封裝： PLASTIC, BGA-388
文件頁數： 23/59頁
文件大小： 932K
代理商： STPCC0390BTC3
STPC CONSUMER-S OVERVIEW
Issue 1.1 - October 16, 2000
3/59
s
PCI Controller
s
Fully compliant with PCI 2.1 specification.
s
Integrated PCI arbitration interface. Up to 3
masters can connect directly. External PAL
allows for greater than 3 masters.
s
Translation of PCI cycles to ISA bus.
s
Translation of ISA master initiated cycle to
PCI.
s
Support for burst read/write from PCI master.
s
PCI clock is 1/3 or 1/2 Host clock .
s
ISA master/slave controller
s
Generates the ISA clock from either
14.318MHz oscillator clock or PCI clock
s
Supports programmable extra wait state for
ISA cycles
s
Supports I/O recovery time for back to back I/
O cycles.
s
Fast Gate A20 and Fast reset.
s
Supports the single ROM that C, D, or E.
blocks shares with F block BIOS ROM.
s
Supports flash ROM.
s
Supports ISA hidden refresh.
s
Buffered DMA & ISA master cycles to reduce
bandwidth utilization of the PCI and Host bus.
NSP compliant.
s
Integrated Peripheral Controller
s
2X8237/AT compatible 7-channel DMA
controller.
s
2X8259/AT compatible interrupt Controller.
16 interrupt inputs - ISA and PCI.
s
Three 8254 compatible Timer/Counters.
s
Co-processor error support logic.
s
Supports external RTC.
s
Local Bus interface
s
Multiplxed with ISA interface.
s
Low latency bus
s
22-bit address bus.
s
16-bit data bus with word steering capability.
s
Programmable timing (Host clock granularity)
s
2 Programmable Flash Chip Select.
s
4 Programmable I/O Chip Select.
s
Supports 32-bit Flash burst.
s
2-level hardware key protection for Flash boot
block protection.
s
Supports 2 banks of 8MB flash devices with
boot block shadowed to 0x000F0000.
s
IDE Interface
s
Supports PIO and Bus Master IDE
s
Supports up to Mode 5 Timings
s
Transfer Rates to 22 MBytes/sec
s
Supports up to 4 IDE devices
s
Concurrent channel operation (PIO & DMA
modes) - 4 x 32-Bit Buffer FIFO per channel
s
Support for PIO mode 3 & 4.
s
Support for DMA mode 1 & 2.
s
Bus Master with scatter/gather capability
s
Multi-word DMA support for fast IDE drives
s
Individual drive timing for all four IDE devices
s
Supports both legacy & native IDE modes
s
Supports hard drives larger than 528MB
s
Support for CD-ROM and tape peripherals
s
Backward compatibility with IDE (ATA-1).
s
Power Management
s
Four power saving modes: On, Doze,
Standby, Suspend.
s
Programmable system activity detector
s
Supports SMM.
s
Supports STOPCLK.
s
Supports IO trap & restart.
s
Independent peripheral time-out timer to
monitor hard disk, serial & parallel ports.
s
Supports RTC, interrupts and DMAs wake-up
