參數資料
| 型號： | M38C24M4A-XXXFP |
| 元件分類： | 微控制器/微處理器 |
| 英文描述： | 8-BIT, MROM, 5 MHz, MICROCONTROLLER, PQFP64 |
| 封裝： | 14 X 14 MM, 0.80 MM PITCH, PLASTIC, LQFP-64 |
| 文件頁數： | 60/102頁 |
| 文件大?。?/td> | 1369K |
| 代理商： | M38C24M4A-XXXFP |
第1頁第2頁第3頁第4頁第5頁第6頁第7頁第8頁第9頁第10頁第11頁第12頁第13頁第14頁第15頁第16頁第17頁第18頁第19頁第20頁第21頁第22頁第23頁第24頁第25頁第26頁第27頁第28頁第29頁第30頁第31頁第32頁第33頁第34頁第35頁第36頁第37頁第38頁第39頁第40頁第41頁第42頁第43頁第44頁第45頁第46頁第47頁第48頁第49頁第50頁第51頁第52頁第53頁第54頁第55頁第56頁第57頁第58頁第59頁當前第60頁第61頁第62頁第63頁第64頁第65頁第66頁第67頁第68頁第69頁第70頁第71頁第72頁第73頁第74頁第75頁第76頁第77頁第78頁第79頁第80頁第81頁第82頁第83頁第84頁第85頁第86頁第87頁第88頁第89頁第90頁第91頁第92頁第93頁第94頁第95頁第96頁第97頁第98頁第99頁第100頁第101頁第102頁
Rev.2.00
May 28, 2004
page 60 of 100
38C2 Group (A Version)
Notes on CPU Rewrite Mode
Take the notes described below when rewriting the flash memory in
CPU rewrite mode.
qOperation speed
During CPU rewrite mode, set the system clock
φ to 4.0 MHz or less
using the main clock division ratio selection bits (bits 4 and 5 of ad-
dress 003B16).
qInstructions inhibited against use
The instructions which refer to the internal data of the flash memory
cannot be used during CPU rewrite mode.
qInterrupts inhibited against use
The interrupts cannot be used during CPU rewrite mode because
they refer to the internal data of the flash memory.
qWatchdog timer
If the watchdog timer has been already activated, internal reset due
to an underflow will not occur because the watchdog timer is surely
cleared during program or erase.
qReset
Reset is always valid. The MCU is activated using the boot mode at
release of reset in the condition of CNVss = “H”, so that the program
will begin at the address which is stored in addresses FFFC16 and
FFFD16 of the boot ROM area.
