Datasheet
IBM PowerPC 750GL RISC Microprocessor
Preliminary
DD1.X
750GL_ds_body.fm 1.2
March 13, 2006
Dimensions and Signal Assignments
Page 39 of 74
TT[0:4]
D14, B17, B14, A15, B13
High
Input/Output
VDD
C10, C11, E8, E13, F6, F9, F12, F15, J8, J9, J13, K3,
K8, K11, K13, K18, L3, L8, L11, L13, L18, M8, M9,
M13, R6, R9, R12, R15, T8, T13, V10, V11
——
WT
U5
Low
Output
Table 4-1. Pinout Listing for the CBGA package (Continued)
Signal Name
Pin Number
Active
Input/Output
Notes
Notes:
1. These are test signals for factory use only and must be pulled up to OVDD for normal machine operation.
2. OVDD inputs supply power to the input/output drivers and VDD inputs supply power to the processor core.
3. These pins are reserved for potential future use.
4. BVSEL and L1_TSTCLK select the input/output voltage mode on the 60x bus.
5. TCK must be tied high or low for normal machine operation.
6. Address and data parity should be left floating if unused in the design.
