56F805 Technical Data
2.5 Interrupt and Program Control Signals
Table 9. Bus Control Signals
No. of
Pins
Signal
Name
Signal
Type
State During
Reset
Signal Description
1
PS
Output
Tri-stated
Program Memory Select
—PS is asserted low for external
Program memory access.
1
DS
Output
Tri-stated
Data Memory Select
—DS is asserted low for external Data
memory access.
1
WR
Output
Tri-stated
Write Enable
—WR is asserted during external memory write
cycles. When WR is asserted low, pins D0–D15 become
outputs and the device puts data on the bus. When WR is
deasserted high, the external data is latched inside the
external device. When WR is asserted, it qualifies the A0–A15,
PS, and DS pins. WR can be connected directly to the WE pin
of a Static RAM.
1
RD
Output
Tri-stated
Read Enable
—RD is asserted during external memory read
cycles. When RD is asserted low, pins D0–D15 become inputs
and an external device is enabled onto the device’s data bus.
When RD is deasserted high, the external data is latched
inside the device. When RD is asserted, it qualifies the A0–
A15, PS, and DS pins. RD can be connected directly to the OE
pin of a Static RAM or ROM.
Table 10. Interrupt and Program Control Signals
No. of
Pins
Signal
Name
Signal
Type
State
During
Reset
Signal Description
1
IRQA
Input
(Schmitt)
Input
External Interrupt Request A
—The IRQA input is a synchronized
external interrupt request indicating an external device is requesting
service. It can be programmed to be level-sensitive or negative-
edge-triggered.
1
IRQB
Input
(Schmitt)
Input
External Interrupt Request B
—The IRQB input is an external
interrupt request indicating an external device is requesting service.
It can be programmed to be level-sensitive or negative-edge-
triggered.
1
RESET
Input
(Schmitt)
Input
Reset
—This input is a direct hardware reset on the processor.
When RESET is asserted low, the device is initialized and placed in
the Reset state. A Schmitt trigger input is used for noise immunity.
When the RESET pin is deasserted, the initial chip operating mode
is latched from the EXTBOOT pin. The internal reset signal will be
deasserted synchronous with the internal clocks, after a fixed
number of internal clocks.
To ensure complete hardware reset, RESET and TRST should be
asserted together. The only exception occurs in a debugging
environment when a hardware device reset is required and it is
necessary not to reset the OnCE/JTAG module. In this case, assert
RESET, but do not assert TRST.
