參數資料
| 型號： | GS8162V18AGB-350I |
| 廠商： | GSI TECHNOLOGY |
| 元件分類： | SRAM |
| 英文描述： | 1M X 18 CACHE SRAM, 4.5 ns, PBGA119 |
| 封裝： | PLASTIC, BGA-119 |
| 文件頁數： | 14/37頁 |
| 文件大?。?/td> | 947K |
| 代理商： | GS8162V18AGB-350I |
第1頁第2頁第3頁第4頁第5頁第6頁第7頁第8頁第9頁第10頁第11頁第12頁第13頁當前第14頁第15頁第16頁第17頁第18頁第19頁第20頁第21頁第22頁第23頁第24頁第25頁第26頁第27頁第28頁第29頁第30頁第31頁第32頁第33頁第34頁第35頁第36頁第37頁
Rev: 1.00a 6/2003
21/37
2003, Giga Semiconductor, Inc.
Specifications cited are subject to change without notice. For latest documentation see http://www.gsitechnology.com.
GS8162V18A(B/D)/GS8162V36A(B/D)/GS8162V72A(C)
Preliminary
AC Electrical Characteristics
Notes:
1. These parameters are sampled and are not 100% tested.
2. ZZ is an asynchronous signal. However, in order to be recognized on any given clock cycle, ZZ must meet the specified setup and hold times as
specified above.
Parameter
Symbol
-350
-333
-300
-250
-200
-150
Unit
Min
Max
Min
Max
Min
Max
Min
Max
Min
Max
Min
Max
Pipeline
Clock Cycle Time
tKC
2.85
—
3.0
—
3.3
—
4.0
—
5.0
—
6.7
—
ns
Clock to Output Valid
(x18/x36)
tKQ
—
1.8
—
2.0
—
2.2
—
2.3
—
2.7
—
3.3
ns
Clock to Output Valid
(x72)
tKQ
—
———
—
2.5
—
2.6
—
2.8
—
3.3
ns
Clock to Output Invalid
tKQX
1.0
—
1.0
—
1.0
—
1.0
—
1.0
—
1.0
—
ns
Clock to Output in Low-Z
tLZ1
1.0
—
1.0
—
1.0
—
1.0
—
1.0
—
1.0
—
ns
Setup time
tS
1.0
—
1.0
—
1.0
—
1.2
—
1.4
—
1.5
—
ns
Hold time
tH
0.1
—
0.1
—
0.1
—
0.2
—
0.4
—
0.5
—
ns
Flow
Through
Clock Cycle Time
tKC
4.5
—
4.7
—
5.0
—
5.5
—
6.5
—
7.5
—
ns
Clock to Output Valid
tKQ
—
4.5
—
4.7
—
5.0
—
5.5
—
6.5
—
7.5
ns
Clock to Output Invalid
tKQX
3.0
—
3.0
—
3.0
—
3.0
—
3.0
—
3.0
—
ns
Clock to Output in Low-Z
tLZ1
3.0
—
3.0
—
3.0
—
3.0
—
3.0
—
3.0
—
ns
Setup time
tS
1.3
—
1.4
—
1.4
—
1.5
—
1.5
—
1.5
—
ns
Hold time
tH
0.3
—
0.4
—
0.4
—
0.5
—
0.5
—
0.5
—
ns
Clock HIGH Time
tKH
1.0
—
1.0
—
1.3
—
1.3
—
1.3
—
1.5
—
ns
Clock LOW Time
tKL
1.2
—
1.2
—
1.5
—
1.5
—
1.5
—
1.7
—
ns
Clock to Output in
High-Z
(x18/x36)
tHZ1
1.0
1.8
1.0
2.0
1.0
2.2
1.0
2.3
1.0
2.7
1.0
3.0
ns
Clock to Output in
High-Z
(x72)
tHZ1
—
———
1.0
2.5
1.0
2.6
1.0
2.8
1.0
3.0
ns
G to Output Valid
(x18/x36)
tOE
—
1.8
—
2.0
—
2.2
—
2.3
—
2.7
—
3.3
ns
G to Output Valid
(x72)
tOE
—
———
—
2.5
—
2.6
—
2.8
—
3.3
ns
G to output in Low-Z
tOLZ1
0
—
0
—
0
—
0
—
0
—
0
—
ns
G to output in High-Z
(x18/x36)
tOHZ1
—
1.8
—
2.0
—
2.2
—
2.3
—
2.7
—
3.0
ns
G to output in High-Z
(x72)
tOHZ1
—
———
—
2.5
—
2.6
—
2.8
—
3.0
ns
ZZ setup time
tZZS2
5
—
5
—
5
—
5
—
5
—
5
—
ns
ZZ hold time
tZZH2
1
—
1
—
1
—
1
—
1
—
1
—
ns
ZZ recovery
tZZR
20
—
20
—
20
—
20
—
20
—
20
—
ns
