參數資料
型號： DS2152L+
廠商： Maxim Integrated Products
文件頁數： 20/97頁
文件大小： 0K
描述： IC TXRX T1 1CHIP ENHNCD 100-LQFP
產品培訓模塊： Lead (SnPb) Finish for COTS
Obsolescence Mitigation Program
標準包裝： 90
功能： 單芯片收發器
接口： T1
電路數： 1
電源電壓： 4.75 V ~ 5.25 V
電流 - 電源： 75mA
工作溫度： 0°C ~ 70°C
安裝類型： 表面貼裝
封裝/外殼： 100-LQFP
供應商設備封裝： 100-LQFP（14x14）
包裝： 管件
包括： DSX-1 和 CSU 線路補償發生器，HDLC 控制器，帶內回路代碼發生器和檢測器
產品目錄頁面： 1429 (CN2011-ZH PDF)
DS2152
27 of 97
CCR4: COMMON CONTROL REGISTER 4 (Address = 11 Hex)
(MSB)
(LSB)
RSRE
RPCSI
RFSA1
RFE
RFF
THSE
TPCSI
TIRFS
SYMBOL
POSITION NAME AND DESCRIPTION
RSRE
CCR4.7
Receive Side Signaling Reinsertion Enable. See Section 8.2 for
details.
0 = do not re-insert signaling bits into the data stream presented at the
RSER pin
1 = re-insert the signaling bits into data stream presented at the RSER
pin
RPCSI
CCR4.6
Receive Per-Channel Signaling Insert. See Section 8.2 for more
details.
0 = do not use RCHBLK to determine which channels should have
signaling re-inserted
1 = use RCHBLK to determine which channels should have signaling
re-inserted
RFSA1
CCR4.5
Receive Force Signaling All 1s. See Section 8.2 for more details.
0 = do not force extracted robbed-bit signaling bit positions to a 1
1 = force extracted robbed-bit signaling bit positions to a 1
RFE
CCR4.4
Receive Freeze Enable. See Section 8.2 for details.
0 = no freezing of receive signaling data will occur
1 = allow freezing of receive signaling data at RSIG (and RSER if
CCR4.7 = 1).
RFF
CCR4.3
Receive Force Freeze. Freezes receive side signaling at RSIG (and
RSER if CCR4.7 = 1); will override Receive Freeze Enable (RFE). See
Section 8.2 for details.
0 = do not force a freeze event
1 = force a freeze event
THSE
CCR4.2
Transmit Hardware Signaling Insertion Enable. See Section 8.2 for
details.
0 = do not insert signaling from the TSIG pin into the data stream
presented at the TSER pin
1 = insert the signaling from the TSIG pin into data stream presented at
the TSER pin
TPCSI
CCR4.1
Transmit Per-Channel Signaling Insert. See Section 8.2 for details.
0 = do not use TCHBLK to determine which channels should have
signaling inserted from TSIG
1 = use TCHBLK to determine which channels should have signaling
inserted from TSIG
TIRFS
CCR4.0
Transmit Idle Registers (TIR) Function Select. See Section 9 for
timing details.
0 = TIRs define in which channels to insert idle code
1 = TIRs define in which channels to insert data from RSER (i.e., Per-
Channel Loopback function)
