Absolute Maximum Ratings
(Note 1)
If Military/Aerospace specified devices are required,
please contact the National Semiconductor Sales Office/
Distributors for availability and specifications.
Supply Voltage (V
DD
)
BLVDS Input Voltage
(Rin
±
)
Maximum Package
Power Dissipation
Capacity
@
25C
Package Thermal Resistance
θ
JA
196 LBGA:
θ
JC
196 LBGA:
Storage Temp. Range
-0.3 to 3.8V
-0.3V to +3.9V
3.7W
34C/W
8C/W
-65C to +150C
Junction Temperature
Lead Temperature
(Soldering 10 Seconds)
ESD Ratings:
Human Body Model
Machine Model
+110C
+225C
>
2KV
>
750V
Recommended Operating
Conditions
Supply Voltage (V
DD
)
Operating Free Air
Temperature (T
A
)
3.0V to 3.6V
-40C to +85C
Electrical Characteristics
Over recommended operating supply and temperature ranges unless otherwise specified. (Note 2)
Symbol
LVCMOS/LVTTL DC Specifications:
High Level Input
Voltage
Low Level Input
Voltage
V
CL
Input Clamp Voltage
I
IN
Input Current
Parameter
Conditions
Pin/Freq.
Min
Typ
Max
Units
V
IH
REN, REFCLK,
PWRDWNn ,
MS_PWRDWN
2.0
V
CC
V
V
IL
GND
0.8
V
-0.87
-1.5
+10
V
uA
V
in
= 0 or 3.6V
-10
I
IN
Input Current
V
in
= 0 or 3.6V
TRST, TMS,
TDI,
BIST_SEL[0:2]
-20
+20
uA
V
OH
High Level Output
Voltage
Low Level Output
Voltage
Output short Circuit
Current
I
OH
= 6mA
ROUT,
RCLK,
LOCKn
2
3
V
CC
V
V
OL
I
OL
= 6mA
GND
0.18
0.5
V
I
OS
V
out
= 0V
-15
-46
-85
mA
I
OZ
TRI-STATE Output
Current
MS_PWRDWN
or REN = 0.8V
V
out
= 0V or
V
CC
-10
±
0.2
+10
μA
V
OH
High Level Output
Voltage
Low Level Output
Voltage
TRI-STATE Output
Current
I
OH
= 12mA
TDO
2
V
CC
V
V
OL
I
OL
= 12mA
GND
0.5
V
I
OS
V
out
= 0V
-15
-120
mA
Bus LVDS DC specifications
Differential Threshold
High Voltage
Differential Threshold
Low Voltage
V
TH
VCM = 0.025,
1.250, 2.375V
(V
RI+
-V
RI-
)
RI+, RI-
+3
+50
mV
V
TL
-50mV
-2
mV
I
IN
Input Current
V
in
= +2.4V,
V
cc
= 3.6 or 0V
V
in
=0V,
V
cc
= 3.6 or 0V
-10
±
1
+10
μA
-10
±
1
+10
μA
S
www.national.com
2
