Electrical Characteristics
MPC5554 Microcontroller Data Sheet, Rev. 2.0
Freescale Semiconductor
9
3.5
ESD (Electromagnetic Static Discharge) Characteristics
3.6
Voltage Regulator Controller (VRC) and
Power-On Reset (POR) Electrical Specifications
The following table lists the VRC and POR electrical specifications:
Table 5. ESD Ratings1, 2
1 All ESD testing conforms to CDF-AEC-Q100 Stress Test Qualification for Automotive Grade Integrated Circuits.
2 Device failure is defined as: if after exposure to ESD pulses, the device no longer meets the device specification requirements.
Complete DC parametric and functional testing will be performed per applicable device specification at room temperature
followed by hot temperature, unless specified otherwise in the device specification.
Characteristic
Symbol
Value
Unit
ESD for human body model (HBM)
2000
V
HBM circuit description
R1
1500
Ω
C100
pF
ESD for field induced charge model (FDCM)
500 (all pins)
V
750 (corner pins)
Number of pulses per pin:
Positive pulses (HBM)
Negative pulses (HBM)
—
1
—
Interval of pulses
—
1
second
Table 6. VRC/POR Electrical Specifications
Spec
Characteristic
Symbol
Min
Max
Units
1
1.5 V (VDD) POR negated (ramp up)
1.5 V (VDD) POR asserted (ramp down)
VPOR15
1.1
1.35
V
2
3.3 V (VDDSYN) POR asserted (ramp up)
3.3 V (VDDSYN) POR negated (ramp up)
3.3 V (VDDSYN) POR asserted (ramp down)
3.3 V (VDDSYN) POR negated (ramp down)
VPOR33
0.0
2.0
0.0
0.30
2.85
0.30
V
3
RESET pin supply (VDDEH6) POR negated (ramp up)
1
RESET pin supply (VDDEH6) POR asserted (ramp down)
VPOR5
2.0
2.85
V
4VRC33 voltage before the regulator controller allows the pass
transistor to start turning on
VTRANS_START
1.0
2.0
V
5VRC33 voltage when the regulator controller allows the pass
transistor to completely turn on 2, 3
VTRANS_ON
2.0
2.85
V
6VRC33 voltage greater than the voltage at which the VRC keeps the
1.5 V supply in regulation4, 5
VVRC33REG
3.0
—
V
7
Current can be sourced by VRCCTL at Tj:
IVRCCTL
6
mA
– 55o C7
11.0
—
mA
– 40o C
11.0
—
mA
25o C
9.0
—
mA
150o C
7.5
—
mA
