參數資料
型號： AT91SAM9XE512-QU
廠商： Atmel
文件頁數： 132/159頁
文件大?。?/td> 0K
描述： MCU ARM9 512K FLASH 208-PQFP
產品培訓模塊： MCU Product Line Introduction
標準包裝： 24
系列： SAM9XE
核心處理器： ARM9
芯體尺寸： 16/32-位
速度： 180MHz
連通性： EBI/EMI，以太網，I²C，MMC，SPI，SSC，UART/USART，USB
外圍設備： 欠壓檢測/復位，POR，PWM，WDT
輸入/輸出數： 96
程序存儲器容量： 512KB（512K x 8）
程序存儲器類型： 閃存
RAM 容量： 56K x 8
電壓 - 電源 (Vcc/Vdd)： 1.65 V ~ 1.95 V
數據轉換器： A/D 4x10b
振蕩器型： 內部
工作溫度： -40°C ~ 85°C
封裝/外殼： 208-MQFP，208-PQFP
包裝： 托盤
配用： AT91SAM9XE-EK-ND - KIT EVAL FOR AT91SAM9XE
AT91SAM-ICE-ND - EMULATOR FOR AT91 ARM7/ARM9
PIC16F5X
DS41213D-page 62
2007 Microchip Technology Inc.
11.3
DC Characteristics PIC16F5X
DC CHARACTERISTICS
Standard Operating Conditions (unless otherwise specified)
Operating Temperature
-40
°C ≤ TA ≤ +85°C for industrial
-40
°C ≤ TA ≤ +125°C for extended
Param
No.
Sym.
Characteristic
Min.
Typ
Max.
Units
Conditions
VIL
Input Low Voltage
D030
I/O Ports
MCLR (Schmitt Trigger)
T0CKI (Schmitt Trigger)
OSC1 (Schmitt Trigger)
OSC1
VSS
—
0.8V
0.15 VDD
0.3 VDD
0.3
V
4.5V <VDD
≤ 5.5V
VDD
≤ 4.5V
RC mode(3)
HS mode
XT mode
LP mode
VIH
Input High Voltage
D040
I/O ports
MCLR (Schmitt Trigger)
T0CKI (Schmitt Trigger)
OSC1 (Schmitt Trigger)
OSC1
2.0
0.25 VDD + 0.8
0.85 VDD
0.7 VDD
1.6
—
VDD
V
4.5V < VDD
≤ 5.5V
VDD
≤ 4.5V
RC mode(3)
HS mode
XT mode
LP mode
IIL
Input Leakage Current(1, 2)
D060
I/O ports
MCLR
T0CKI
OSC1
—
±1.0
±5.0
μA
VSS
≤ VPIN ≤ VDD,
pin at high-impedance
VSS
≤ VPIN ≤ VDD
VSS
≤ VPIN ≤ VDD
VSS
≤ VPIN ≤ VDD,
XT, HS and LP modes
VOL
Output Low Voltage
D080
D083
I/O ports
OSC2/CLKOUT
(RC mode)
—
0.6
V
IOL = 8.5 mA, VDD = 4.5V
IOL = 1.6 mA, VDD = 4.5V
VOH
Output High Voltage(2)
D090
D092
I/O ports(2)
OSC2/CLKOUT
(RC mode)
VDD – 0.7
—
V
IOH = -3.0 mA, VDD = 4.5V
IOH = -1.3 mA, VDD = 4.5V
*
These parameters are characterized but not tested.
Data in the Typical (“Typ”) column is based on characterization results at 25
°C. This data is for design
guidance only and is not tested.
Note 1:
The leakage current on the MCLR/VPP pin is strongly dependent on the applied voltage level. The
specified levels represent normal operating conditions. Higher leakage current may be measured at
different input voltage.
2:
Negative current is defined as coming out of the pin.
3:
For the RC mode, the OSC1/CLKIN pin is a Schmitt Trigger input. It is not recommended that the
PIC16F5X be driven with external clock in RC mode.
