參數資料
型號： TDA8757CHV/21
廠商： NXP SEMICONDUCTORS
元件分類： ADC
英文描述： 3-CH 8-BIT PROPRIETARY METHOD ADC, PARALLEL ACCESS, PQFP144
封裝： 20 X 20 MM, 1.40 MM HEIGHT, PLASTIC, SOT-612-1, HLQFP-144
文件頁數： 3/38頁
文件大?。?/td> 894K
代理商： TDA8757CHV/21
Philips Semiconductors
TDA8757C
Triple 8-bit ADC 205 Msps
Preliminary data
Rev. 01 — 14 August 2002
11 of 38
9397 750 10111
Koninklijke Philips Electronics N.V. 2002. All rights reserved.
A6R
120
red channel ADC output A bit 6
A7R
121
red channel ADC output A bit 7 (MSB)
OGNDPLL
122
PLL digital ground
CKDATA
123
output data clock
CKREFO
124
output horizontal pulse synchronized to pixel clock
TESTO
125
output reserved for test
VCCO(PLL)
126
PLL output supply voltage
n.c.
127
not connected
DGND1
128
digital ground 1
SW2
129
output pin SW2 is controlled by the I2C-bus
SW1
130
output pin SW1 is controlled by the I2C-bus
CLP
131
clamp pulse input (clamp active HIGH)
HSYNC
132
horizontal synchronization pulse input
INV
133
PLL clock output inverter control input (invert when HIGH)
CKEXT
134
external clock input
COAST
135
PLL coast control input
CKREF
136
PLL reference clock input
VCCD1
137
digital supply voltage 1
n.c.
138
not connected
AGNDPLL
139
PLL analog ground
CP
140
PLL lter input
CZ
141
PLL lter input
AGNDPLL
142
PLL analog ground
VCCA(PLL)
143
PLL analog supply voltage
n.c.
144
not connected
GNDDP
exposed die pad connection
Table 3:
Pin description…continued
Symbol
Pin
Description
