76
CHAPTER 3: ELECTRICAL SPECIFICATIONS
C3ENPA1-DS/D REV 03
MOTOROLA GENERAL BUSINESS INFORMATION
large mass of the heat sink, attachment through the printed circuit board is suggested. If a
spring clip is used, the spring force should not exceed 5.5 pounds.
Figure 10
Package Cross Section View with Serveral Heat Sink Options
Internal Package Conduction Resistance
For the exposed-die packaging technology the intrinsic conduction thermal resistance
paths are as follows:
The die junction-to-case (or top-of-die for exposed silicon) thermal resistance
The die junction-to-ball thermal resistance
Figure 11
depicts the primary heat transfer path for a package with an attached heat sink
mounted to a printed-circuit board.
CBGA Package
Heat Sink
Heat Sink Clip
Thermal Interface Material
Printed Circuit Board
F
n
.
