FireLink USB
82C862
912-2000-030
Revision: 1.0
Page 44
6.3.3 USB AC Timings: Low Speed Source
Sym
Parameter
Min
Max
Unit
Figure
Condition (Notes 1, 2, and 4)
Driver Characteristics
tR
tF
Transition Time:
Rise Time
Fall Time
75
75
300
300
ns
ns
Notes 5 and 6
Min# measured with: CL = 50pF
Max# measured with: CL = 350pF
tRFM
Rise/Fall Time Matching
80
120
%
(tR/tF)
vCRS
Output Signal Crossover Voltage
1.3
2.0
V
Data Source Timings
tDRATE
Low Speed Data Rate
1.4775
1.5225
Mb/s
Average bit rate = 1.5Mb/s ±1.5%
tDDJ1
tDDJ2
Source Differential Driver Jitter,
At Host (Downstream):
To Next Transition
For Paired Transitions
–75
–45
75
45
ns
ns
Notes 7 and 8
tUDJ1
tUDJ2
Source Differential Driver Jitter,
At Function (Upstream):
To Next Transition
For Paired Transitions
–95
–150
95
150
ns
ns
Notes 7 and 8
tEOPT
Source EOP Width
1.25
150
μs
6-5
Note 8
tDEOP
Differential to EOP Transition Skew
–40
100
ns
6-5
Note 8
tUJR1
tUJR2
Receiver Data Jitter Tolerance,
At Host (Upstream):
To Next Transition
For Paired Transitions
–152
–200
152
200
ns
ns
6-6
tDJR1
tDJR2
Receiver Data Jitter Tolerance,
At Function (Downstream):
To Next Transition
For Paired Transitions
–75
–45
75
45
ns
ns
6-6
tEOPR1
tEOPR2
Notes:
1. All voltages measured from the local ground potential, unless otherwise specified.
EOP Width at Receiver:
Must Reject at EOP
Must Accept as EOP
330
675
ns
ns
6-6
Note 8
2. All timings use a capacitive load (CL) to ground of 50pF, unless otherwise specified.
3. Full speed timings have a 1.5 kohm pull-up to 2.8V on the D+ data line.
4. Low speed timings have a 1.5 kohm pull-up to 2.8V on the D– line.
5. Measured from 10% to 90% of the data signal.
6. The rising and falling edges should be smoothly transitioning (monotonic).
7. Timing difference between the differential data signals.
8. Measured at crossover point of differential data signals.
9. The maximum load specification is the maximum effective capacitive load allowed that meets the target hub Vbus
droop of 330mV.
