TS8388BG
8/46
Test
level
Unit
Max
Typ
Min
Temp
Symb
Parameter
TRANSIENT PERFORMANCE
Bit Error Rate
(notes 2, 4)
FS = 1 GSPS
Fin = 62.5 MHz
BER
IV
10–13
error/
sample
ADC settling time
(note 2)
VIn –VinB = 400 mVpp
TS
IV
0.5
ns
Overvoltage recovery time
(note 2)
ORT
IV
0.5
ns
AC PERFORMANCE
Single ended or differential input mode, 50 % clock duty cycle (CLK,CLKB), Binary output data format,
Tj. = 70
°C, unless otherwise specified.
Signal to Noise and Distortion ratio
(note 2)
SINAD
FS = 1 GSPS
Fin = 20 MHz
44.3
dB
FS = 1 GSPS
Fin = 500 MHz
43
dB
FS = 1 GSPS
Fin = 1000 MHz (–1dB Fs)
39.7
dB
Effective Number Of bits
ENOB
FS = 1 GSPS
Fin = 20 MHz
7.2
Bits
FS = 1 GSPS
Fin = 500 MHz
7.0
Bits
FS = 1 GSPS
Fin = 1000 MHz (–1dBFs)
6.4
Bits
Signal to Noise Ratio
(note 2)
SNR
FS = 1 GSPS
Fin = 20 MHz
44.7
dB
FS = 1 GSPS
Fin = 500 MHz
44.1
dB
FS = 1 GSPS
Fin = 1000 MHz (–1dBFs)
43.4
dB
Total Harmonic Distorsion
(note 2)
THD
FS = 1 GSPS
Fin = 20 MHz
–54
dBc
FS = 1 GSPS
Fin = 500 MHz
–50
dBc
FS = 1 GSPS
Fin = 1000 MHz (–1dBFs)
–42
dBc
Spurious Free Dynamic Range
(note 2)
SFDR
FS = 1 GSPS
Fin = 20 MHz
57
dBc
FS = 1 GSPS
Fin = 500 MHz
52
dBc
FS = 1 GSPS
Fin = 1000 MHz (–1dBFs)
43
dBc
FS = 1 GSPS
Fin = 1000 MHz (–3dBFs)
49
dBc
Two–tone intermodulation distortion
(note 2)
IMD
FIN1 = 489 MHz @ FS=1 GSPS
–52
dB
FIN2 = 490 MHz @ FS=1 GSPS
