INPUT/OUTPUT PORTS
4-6
Port D bit 1 becomes the Transmit Data output (TXD) when the SCI transmitter is enabled (TE bit
in the SCCR2 register set to one). When the TE bit is clear, Port D bit 1 defaults to being a general
purpose I/O pin controlled by DDRD. Note that the transmit logic will retain control of Port D bit 1 after
TE is cleared until all transmit operations have finished, including completion of transmission of data
from the serial shifter, a queued idle, or queued break.
In a test mode, the RCKB test bit in the BAUD register may be set. When RCKB is set, the 16X
receiver baud rate clock and the 1X transmitter clock are exclusive-ORed and driven out of the Port
D bit 1 pin. The RCKB bit can be written only in the test or bootstrap modes and it overrides any other
use of the Port D bit 1 pin.
Bits 2 – 5 of Port D are dedicated to the serial peripheral interface function (SPI) whenever the SPE
bit in the SPCR register is set (SPI enabled). Note that Port D bit 5 still responds to DDRD bit 5 such
that, if the DDR bit is set, the Port D bit 5 pin is given up by the SPI system to become a general
purpose output pin if and only if the SPI is in master mode. When the SPE bit is clear, bits 2 – 5 of
Port D default to being general purpose I/O pins controlled by DDRD.
The four SPI interface lines are described in greater detail in SECTION 8: SERIAL PERIPHERAL
INTERFACE.
4.7.1
Data Register (PORTD)
0
PD5
PD4
PD3
PD2
PD1
PD0
PORTD
$1008
7
6
5
4
3
2
1
0
RESET:
Alternate Pin Function:
—
SS
SCK
MOSI
MISO
TXD
RXD
READ:
Any time (inputs return pin level; outputs return pin driver input level). Bits 6 and 7 always
read as zeros.
WRITE:
Data stored in internal latch (drives pins only if configured as outputs). Writes to bit 6 and
7 have no meaning or effect.
RESET:
Bits 0 – 5 are configured as general purpose inputs.
4.7.2
Data Direction Register (DDRD)
0
DDD5
DDD4
DDD3
DDD2
DDD1
DDD0
DDRD
$1009
7
6
5
4
3
2
1
0
RESET:
READ:
Any time (reads of bits 6 and 7 always return zeros).
WRITE:
Any time (writes to bits 6 and 7 have no meaning or effect).
