Confidential
29
www.national.com
Register Set (continued)
Register Name Integration Time High Register
Address
13 Hex
Mnemonic
ITIMEH
Type
Read/Write
Reset Value
00 Hex.
Register Name Integration Time Low Register
Address
14 Hex
Mnemonic
ITIMEL
Type
Read/Write
Reset Value
00 Hex.
Register Name Row Delay High Register
Address
15 Hex
Mnemonic
RDELAYH
Type
Read/Write
Reset Value
00 Hex.
Register Name Row Delay Low Register
Address
16 Hex
Mnemonic
RDELAYL
Type
Read/Write
Reset Value
00 Hex
Register Name Frame Delay High Register
Address
17
Mnemonic
FDELAYH
Type
Read/Write
Reset Value
00 Hex
Register Name Frame Delay Low Register
Address
18 Hex
Mnemonic
FDELAYL
Type
Read/Write
Reset Value
00 Hex
Register Name Video Gain Register
Address
19 Hex
Mnemonic
VGAIN
Type
Read/Write
Reset Value
00 Hex
Register Name Offset Compensation Register 0
address
1FHex
Mnemonic
OCR0
Type
Read/Write
Reset Value
00 Hex
Register Name Offset Compensation Register 1
address
22 Hex
Mnemonic
OCR1
Type
Read/Write
Reset Value
00 Hex
Register Name Offset Compensation Register 2
address
25 Hex
Mnemonic
OCR2
Type
Read/Write
Reset Value
00 Hex
Bit
Bit Symbol
Description
7:4
Reserved
3:0
Itime[11:8]
Program to set the integration
time of the array. The value pro-
grammed in the register is the
number of rows ahead of the
selected row to be reset.
Bit
Bit Symbol
Description
7:0
Itime[7:0]
Program to set the integration
time of the array. The value pro-
grammed in the register is the
number of rows ahead of the
selected row to be reset.
Bit
Bit Symbol
Description
7:3
Reserved
2:0
Rdelay[10:8]
Use to program the MSBs of the
row delay.
Bit
Bit Symbol
Description
7:0
Rdelay[7:0]
Use to program the LSBs of the
row delay.
Bit
Bit Symbol
Description
7:4
Reserved
3:0
FDelay[11:8]
Use to program the MSBs of the
frame delay.
Bit
Bit Symbol
Description
7:0
FDelay [7:0]
Use to program the LSBs of
the frame delay.
Bit
Bit Symbol
Description
7:6
Reserved
5:0
VidGain
Use to program the overall video
gain. 00hex corresponds to a gain
of 0dB while 3Fhex corresponds
to a gain of 15dB. Steps are in lin-
ear increments.
Bit
Bit Symbol
Description
7:0
OffsetVol
This register defines the volt-
age level appearing on the
offset_ctrl pin.
Bit
Bit Symbol
Description
7:0
OffsetVol
This register defines the volt-
age level appearing on the
offset_ctrl pin.
Bit
Bit Symbol
Description
7:0
OffsetVol
This register defines the volt-
age level appearing on the
offset_ctrl pin.
L
M
9
6
1
7
