Confidential
28
www.national.com
Register Set (continued)
Register Name Scan Window Row Start Register
Address
0B Hex
Mnemonic
SROWS
Type
Read/Write
Reset Value
00 Hex
Register Name Scan Window Row End Register
Address
0C Hex
Mnemonic
SROWE
Type
Read/Write
Reset Value
FB Hex
Register Name Display Window Row Start Register
Address
0E Hex
Mnemonic
DROWS
Type
Read/Write
Reset Value
00 Hex
Register Name Display Row End Register
Address
0F Hex
Mnemonic
DROWE
Type
Read/Write
Reset Value
FB Hex
Register Name Display Window Column Start Register
Address
10 Hex
Mnemonic
DCOLS
Type
Read/Write
Reset Value
00 Hex
Register Name Display Window Column End Register
Address
11 Hex
Mnemonic
DCOLE
Type
Read/Write
Reset Value
A5 Hex
Register Name Display Window LSB register
Address
12 Hex
Mnemonic
DWLSB
Type
Read/Write
Reset Value
32 Hex
Bit
Bit Symbol
Description
7:0
SwStartRow
Use to program the scan window’s
start row address MSBs. If bit 6 of
register DWLSB is set to 1 the
start row address is incremented
by 1 else the raw value is used.
Bit
Bit Symbol
Description
7:0
SwEndRow
Use to program the scan window’s
end row address MSBs. If bit 6 of
register DWLSB is set to 1 the end
row address is incremented by 1.
else the raw value is used.
Bit
Bit Symbol
Description
7:0
DwStartRow
Use to program the display win-
dow’s start row address MSBs.
The LSB can be programmed
using the DWLSB register.
Bit
Bit Symbol
Description
7:0
DwEndRow
Use to program the scan window’s
end row address. The LSB can be
programmed using the DWLSB
register.
Bit
Bit Symbol
Description
7:0
DwStartCol
Use to program the display win-
dow’s
start
column
address
MSBs. The two LSBs can be pro-
grammed using the DWLSB regis-
ter.
Bit
Bit Symbol
Description
7:0
DwEndCol
Use to program the scan window’s
end column address MSBs. The
two LSBs can be programmed
using the DWLSB register.
Bit
Bit Symbol
Description
7
Reserved
6
SwLsb
Assert to increment the value of
the scan window start and end
row addresses by 1. Clear (the
default) to use the raw values.
5
DwCel[1]
Use to program bit 1 of the display
window’s end column address.
Default is 1.
4
DwCel[0]
Use to program bit 0 of the display
window’s end column address.
Default is 1.
3
DwCSL[1]
Use to program bit 1 of the display
window’s start column address.
Default is 0.
2
DwCSL [0]
Use to program bit 0 of the display
window’s start column address.
Default is 0.
1
DwERLsb
Use to program bit 0 of the display
window’s
end
row
address.
Default is 1.
0
DwSRLsb
Use to program bit 0 of the display
window’s
start
row
address.
Default is 0.
L
M
9
6
1
7
