PowerPC 405GP Embedded Controller
Data Sheet
Advance Information
IBM Corporation. All rights reserved.
Use is further subject to the provisions at the end of this document.
Page 38 of 48
galdsh5f
06/15/99 Preliminary
Recommended DC Operating Conditions
Notes:
1. PCI drivers meet PCI specifications
2. Operation at junction temperatures up to 125
°C is permitted for derated processor frequencies. Please contact your
IBM Microelectronics representative for the latest processor derating specifications.
Parameter
Symbol
Minimum
Typical
Maximum
Unit
Notes
Logic Supply Voltage
VDD
2.3
2.5
2.7
V
I/O Supply Voltage
OVDD
3.0
3.3
3.6
V
PLL Supply Voltage
AVDD
2.3
2.5
2.7
V
Input Logic High (3.3V LVTTL
receivers)
VIH
2.0
OVDD
V
Input Logic High (5.0V LVTTL
receivers)
VIH
2.0
5.5
V
Input Logic Low
VIL
0
0.8
V
Output Logic High
VOH
2.4
OVDD
V
Output Logic Low
VOL
0
0.4
V
Input Leakage Current (No Pull-Up
or Pull-Down)
IIL1
00
A
Input Leakage Current for Pull-
Down
IIL2
0 (LPDL)
400 (MPUL)
A
Input Leakage Current for Pull-Up
IIL3
250 (LPDL)
0 (MPUL)
A
Input Max Allowable Overshoot
(3.3V LVTTL receivers)
VIMAO3
OVDD + 0.6
V
Input Max Allowable Overshoot
(5.0V LVTTL receivers)
VIMAO5
5.5
V
Input Max Allowable Undershoot
(3.3V or 5.0V receivers)
VIMAU
0.6
V
Output Max Allowable Overshoot
(3.3V or 5.0V receivers)
VOMAO
OVDD + 0.3
V
Output Max Allowable Undershoot
(3.3V and 5.0V receivers)
VOMAU3
0.6
V
Die Junction Temperature
TJ
40
85
°C2
Capacitance
Parameter
Symbol
Maximum
Unit
Notes
Input Capacitance Group 1 (3.3V LVTTL //O)
CIN1
2.5
pF
1, 3
Input Capacitance Group 2 (5V tolerant LVTTL I/O)
CIN2
3.5
pF
2, 3
Input Capacitance Group 3(PCI I/O)
CIN3
5.0
pF
Input Capacitance Group 1 (RX only pins)
CIN4
0.75
pF
相關PDF資料
PDF描述
IBM25EMPPC603EFG-100 32-BIT, 100 MHz, RISC PROCESSOR, PQFP240
IBM25EMPPC603EBG-100 32-BIT, 100 MHz, RISC PROCESSOR, CBGA255
IBM25EMPPC740LDBC4000 32-BIT, 400 MHz, RISC PROCESSOR, CBGA255
IBM25EMPPC750LCBF3330 32-BIT, 333 MHz, RISC PROCESSOR, CBGA360
IBM25EMPPC740LFBF4000 32-BIT, 400 MHz, RISC PROCESSOR, CBGA255
