Copyright 2010 Future Technology Devices International Limited
31
Document No.: FT_000173
FT2232D DUAL USB TO SERIAL UART
/FIFO IC Datasheet
Version 2.05
Clearance No.: FTDI# 127
8 Signal Descriptions by IO Mode and Interface Channel
Configurations
8.0 232 UART Interface Mode Signal Descriptions and Interface
Configurations
When either Channel A or Channel B is in 232 UART mode, the IO signal lines are configured as follows:-
Pin#
Signal
Type
Description
Channel A
Channel B
24
40
TXD
OUTPUT
Transmit Asynchronous Data Output
23
39
RXD
INPUT
Receive Asynchronous Data Input **Note 16
22
38
RTS#
OUTPUT
Request To Send Control Output / Handshake signal
21
37
CTS#
INPUT
Clear To Send Control Input / Handshake signal
**Note 16
20
36
DTR#
OUTPUT
Data Terminal Ready Control Output / Handshake
signal
19
35
DSR#
INPUT
Data Set Ready Control Input / Handshake signal
**Note 16
17
33
DCD#
INPUT
Data Carrier Detect Control Input **Note 16
16
32
RI#
INPUT
Ring Indicator Control Input. When the Remote
Wake up option is enabled in the EEPROM, taking
RI# low can be used to resume the PC USB Host
controller from suspend. **Note 16
15
30
TXDEN
OUTPUT
Enable Transmit Data for RS485
13
29
SLEEP#
OUTPUT
Goes low during USB Suspend Mode. Typically used
to power-down an external TTL to RS232 level
converter I.C. in USB to RS232 converter designs.
12
28
RXLED#
O.C.
LED Drive - Pulses Low when Transmitting Data via
USB.
11
27
TXLED#
O.C
LED Drive - Pulses Low when Receiving Data via
USB.
10
26
SI/WU
INPUT
The Send Immediate / WakeUp signal combines
two functions on a single pin. If USB is in suspend
mode (PWREN# = 1) and remote wakeup is
enabled in the EEPROM , strobing this pin low will
cause the device to request a resume on the USB
Bus. Normally, this can be used to wake up the
Host PC.
During normal operation (PWREN# = 0), if this pin
is strobed low any data in the device TX buffer will
be sent out over USB on the next Bulk-IN request
from the drivers regardless of the pending packet
size. This can be used to optimise USB transfer
speed for some applications. Tie this pin to VCCIO if
not used
Table 8.1 232 UART mode the IO signal lines Description
**Note 16: These pins are pulled to up VCCIO via internal 200K resistors during Reset and USB
Suspend mode. These can be programmed to gently pull low during USB suspend (PWREN#
=“1”) by setting this option in the EEPROM.
