18
Dual-Core Intel Itanium Processor 9000 Series Datasheet
Electrical Specifications
2.4
Signal Specifications
This section describes the DC specifications of the system bus signals. The processor
describe the DC specifications for the AGTL+, PWRGOOD, HSTL clock, TAP port, system
management, and LVTTL signals. Please refer to the ITP700 Debug Port Design Guide
for the TAP connection signals DC specifications at the debug port.
Table 2-3.
Processor Package Specifications
Symbol
Parameter
Core
Frequency
Minimum
Typ
Maximum
Unit
Notes
Vcore, PS
VCC from the Voltage
Regulator
All
VID-17mV
VID
VID+17mV
V
1
Notes:
1. The range for Vcore is 1.0875V to 1.25V.
Vcache, PS
Vcache from the Voltage
Regulator
All
VID-17mV
VID
VID+17mV
V
2
2. Vcache typical is 1.025V.
Vfixed, PS
Vfixed from the Voltage
Regulator
All
1.25-20mV
1.25
1.25+20mV
V
VCTERM
Termination Voltage
All
1.2-1.5%
1.2
1.2+1.5%
V
RTERM
Recommended Termination
Resistance
All
45-15%
45
45+15%
Ohm
3
3. The processor system bus is terminated at each end of the system bus. The processor supports both on-die
and off-die termination which is selected by the TERMA and TERMB pins. Termination tolerance is ±15% for
on-die termination measured at VOL and ±1% for off-die termination.
VTAP
Test Access Port Voltage
(VCCTAP)
All
1.2-1.5%
1.2
1.5
V
Icore,PS
Core Current Required from
Power Supply
All
2.8
89
121
A
Icache,PS
Cache Current Required from
Power Supply
All
2.0
17
18
A
Ifixed,PS
Fixed Current Required from
Power Supply
All
0.7
9.2
11
A
ICTERM
Termination Voltage Current
All
7.2
A
4
4. This is measured for On Die Termination with a 45 ohm pull up resistor.
PSTT
Power Supply Slew Rate for
the Termination Voltage at
the Processor Pins
All
0.05
A/ns
PWRmax
Max Power
All
177
W
5
5. Max power is peak electrical power that must be provided for brief periods by the VR.
PWRTPE
Thermal Power Envelop
All
130
W
PWRTDP
Thermal Design Power – dual
core
All
104
W
6
6. Represents the TDP level that should be used for system thermal design. Sustained power for all real world
applications will remain at or below this power level..
Thermal Design Power –
single core
1.6 GHz
75
W
