The BXB75 Series are high power density dc-dc converters
packaged in the industry standard footprint (2.40 x 2.28 x 0.50
inches) to give designers optimum choices when specifying for
both new and replacement designs. Suitable for a wide range of
applications in nearly any industry, the BXB75 was particularly
designed with communication and distributed power applications
in mind. Using Bellcore 332, the MTBF is greater than 1,400,000
hours. Aluminum baseplate technology with four threaded M3
inserts makes heatsink attachment and optimum thermal
management easy. The BXB75 series is approved to IEC950 by UL,
CSA and VDE.
Embedded Power for
Business-Critical Continuity
BXB75 Series
Single output
Special Features
Industry standard footprint
MTBF >1.4 million hours
(Bellcore 332)
Input voltage to ETS300-132-2
Adjustable output voltage
No minimum load required
Separate case ground pin
2:1 input range for battery
powered applications
Undervoltage lockout (UVLO)
UL, VDE and CSA safety
approvals
Available RoHS compliant
2 year warranty
Total Power:
50 - 75W
Input Voltage: 36 - 75VDC
# of Outputs:
Single
Safety
VDE0805/EN60950/IEC950
File No. 10401-3336-0205
UL1950 File No. E136005
CSA C22.2 No. 950
File No. LR41062C
Rev.03.08.07
bxb75s
1 of 4
