Pin Lists and Signal Descriptions
52
Intel Pentium 4 Processor on 0.13 Micron Process Datasheet
Table 4-2. Pin Listing by Pin Number
Pin
Number
Pin Name
Signal Buffer
Type
Direction
A2
THERMTRIP#
Asynch GTL+
Output
A3
VSS
Power/Other
A4
VSS_SENSE
Power/Other
Output
A5
VCC_SENSE
Power/Other
Output
A6
TESTHI11
Power/Other
Input
A7
RESERVED
A8
VCC
Power/Other
A9
VSS
Power/Other
A10
VCC
Power/Other
A11
VSS
Power/Other
A12
VCC
Power/Other
A13
VSS
Power/Other
A14
VCC
Power/Other
A15
VSS
Power/Other
A16
VCC
Power/Other
A17
VSS
Power/Other
A18
VCC
Power/Other
A19
VSS
Power/Other
A20
VCC
Power/Other
A21
VSS
Power/Other
A22
RESERVED
A23
D2#
Source Synch
Input/Output
A24
VSS
Power/Other
A25
D3#
Source Synch
Input/Output
A26
VSS
Power/Other
AA1
VSS
Power/Other
AA2
TESTHI1
Power/Other
Input
AA3
BINIT#
Common Clock
Input/Output
AA4
VSS
Power/Other
AA5
BPM4#
Common Clock
Input/Output
AA6
GTLREF
Power/Other
Input
AA7
VSS
Power/Other
AA8
VCC
Power/Other
AA9
VSS
Power/Other
AA10
VCC
Power/Other
AA11
VSS
Power/Other
AA12
VCC
Power/Other
AA13
VSS
Power/Other
AA14
VCC
Power/Other
AA15
VSS
Power/Other
AA16
VCC
Power/Other
AA17
VSS
Power/Other
AA18
VCC
Power/Other
AA19
VSS
Power/Other
AA20
ITPCLK[0]
Power/Other
Output
AA21
GTLREF
Power/Other
Input
AA22
D62#
Source Synch
Input/Output
AA23
VSS
Power/Other
AA24
D63#
Source Synch
Input/Output
AA25
D61#
Source Synch
Input/Output
AA26
VSS
Power/Other
AB1
A35#
Source Synch
Input/Output
AB2
RSP#
Common Clock
Input
AB3
VSS
Power/Other
AB4
BPM5#
Common Clock
Input/Output
AB5
BPM1#
Common Clock
Input/Output
AB6
VSS
Power/Other
AB7
VCC
Power/Other
AB8
VSS
Power/Other
AB9
VCC
Power/Other
AB10
VSS
Power/Other
AB11
VCC
Power/Other
AB12
VSS
Power/Other
AB13
VCC
Power/Other
AB14
VSS
Power/Other
AB15
VCC
Power/Other
AB16
VSS
Power/Other
AB17
VCC
Power/Other
AB18
VSS
Power/Other
AB19
VCC
Power/Other
AB20
VSS
Power/Other
AB21
VSS
Power/Other
AB22
ITPCLK[1]
Power/Other
Output
AB23
PWRGOOD
Power/Other
Input
AB24
VSS
Power/Other
AB25
RESET#
Common Clock
Input
AB26
SLP#
Asynch GTL+
Input
AC1
AP#[0]
Common Clock
Input/Output
AC2
VSS
Power/Other
AC3
IERR#
Common Clock
Output
AC4
BPM2#
Common Clock
Input/Output
AC5
VSS
Power/Other
AC6
BPM0#
Common Clock
Input/Output
AC7
VSS
Power/Other
AC8
VCC
Power/Other
AC9
VSS
Power/Other
AC10
VCC
Power/Other
AC11
VSS
Power/Other
Table 4-2. Pin Listing by Pin Number
Pin
Number
Pin Name
Signal Buffer
Type
Direction
