AMIS-30623 LIN Microstepping Motordriver
Data Sheet
15.3.6. Charge Pump Monitoring
If the charge pump voltage is not sufficient for driving the high side transistors (due to a failure), an internal HardStop command is
issued. This is acknowledged to the master by raising flag <CPFail> (available with command GetFullStatus).
In case this failure occurs while a motion is ongoing, the flag <StepLoss> is also raised.
15.3.7. Electrical Defect on Coils, Detection and Confirmation
The principle relies on the detection of a voltage drop on at least one transistor of the H-bridge. Then the decision is taken to open the
transistors of the defective bridge.
This allow to detect the following short circuits:
External coil short circuit
Short between one terminal of the coil and Vbat or Gnd
One cannot detect internal short in the motor
Open circuits are detected by 100% PWM duty cycle value during a long time
Table 24: Electrical Defect Detection
Pins
Fault mode
Yi or Xi
Short circuit to GND
Yi or Xi
Short circuit to Vbat
Yi or Xi
Open
Y1 and Y2
Short circuited
X1 and X2
Short circuited
Xi and Yi
Short circuited
37
AMI Semiconductor
– June 2006, Rev 3.0
www.amis.com
