6.42
IDT70V3319/99S
High-Speed 3.3V 256/128K x 18 Dual-Port Synchronous Static RAM
Industrial and Commercial Temperature Ranges
21
Identification Register Definitions
Instruction Field
Value
Description
Revision Number (31:28)
0x0
Reserved for version number
IDT Device ID (27:12)
0x0314
(1)
Defines IDT part number
IDT JEDEC ID (11:1)
0x33
Allows unique identification of device vendor as IDT
ID Register Indicator Bit (Bit 0)
1
Indicates the presenc e of an ID register
5623 tbl 13
Scan Register Sizes
Register Name
Bit Size
Instruction (IR)
4
Bypass (BYR)
1
Identification (IDR)
32
Boundary Scan (BSR)
Note (3)
5623 tbl 14
System Interface Parameters
Instruction
Code
Description
EXTEST
0000
Forces contents of the boundary scan cells onto the device outputs(1).
Places the boundary scan registe r (BSR) between TDI and TDO.
BYPASS
1111
Places the by pass register (BYR) between TDI and TDO.
IDCODE
0010
Loads the ID register (IDR) with the vendor ID code and places the
register between TDI and TDO.
HIGHZ
0011
Places the bypass register (BYR) be tween TDI and TDO. Forces all
device output drivers to a High-Z state.
SAMPLE/PRELOAD
0001
Places the boundary scan registe r (BSR) between TDI and TDO.
SAMPLE allows data from device inputs
(2) to be captured in the
boundary scan cells and shifted serially through TDO. PRELOAD allows
data to be input serially into the b oundary scan cells via the TDI.
RESERVED
All other codes
Several combinations are reserved. Do not use codes other than those
identified above.
5623 tbl 15
NOTES:
1. Device outputs = All device outputs except TDO.
2. Device inputs = All device inputs except TDI, TMS, and
TRST.
3. The Boundary Scan Descriptive Language (BSDL) file for this device is available on the IDT website (www.idt.com), or by contacting your local
IDT sales representative.
NOTE:
1. Device ID for IDT70V3399 is 0x0315.
