Philips Semiconductors
Preliminary specification
80C554/83C554/87C554
80C51 8-bit microcontroller
16K/512 OTP/ROM/ROMless, 8 channel 10 bit A/D, I
2
C, PWM,
capture/compare, high I/O
1999 Apr 07
33
V
DD
OTHER DEVICE WITH
I
C INTERFACE
8XC554
OTHER DEVICE WITH
I
C INTERFACE
P1.7/SDA
P1.6/SCL
SDA
SCL
I
2
C bus
R
P
R
P
SU00964
Figure 33. Typical I
2
C Bus Configuration
SCL
START
CONDITION
S
SDA
P/S
MSB
ACKNOWLEDGMENT
SIGNAL FROM RECEIVER
CLOCK LINE HELD LOW WHILE
INTERRUPTS ARE SERVICED
1
2
7
8
9
1
2
3–8
ACK
9
ACK
REPEATED IF MORE BYTES
ARE TRANSFERRED
ACKNOWLEDGMENT
SIGNAL FROM RECEIVER
SLAVE ADDRESS
R/W
DIRECTION
BIT
STOP
CONDITION
REPEATED
START
CONDITION
SU00965
Figure 34. Data Transfer on the I
2
C Bus
SIO1 Implementation and Operation:
Figure 35 shows how the
on-chip I
2
C bus interface is implemented, and the following text
describes the individual blocks.
I
NPUT
F
ILTERS
AND
O
UTPUT
S
TAGES
The input filters have I
2
C compatible input levels. If the input voltage
is less than 1.5V, the input logic level is interpreted as 0; if the input
voltage is greater than 3.0V, the input logic level is interpreted as 1.
Input signals are synchronized with the internal clock (f
OSC
/4), and
spikes shorter than three oscillator periods are filtered out.
The output stages consist of open drain transistors that can sink
3mA at V
OUT
< 0.4V. These open drain outputs do not have
clamping diodes to V
DD
. Thus, if the device is connected to the I
2
C
bus and V
DD
is switched off, the I
2
C bus is not affected.
A
DDRESS
R
EGISTER,
S
1
ADR
This 8-bit special function register may be loaded with the 7-bit slave
address (7 most significant bits) to which SIO1 will respond when
programmed as a slave transmitter or receiver. The LSB (GC) is
used to enable general call address (00H) recognition.
C
OMPARATOR
The comparator compares the received 7-bit slave address with its
own slave address (7 most significant bits in S1ADR). It also
compares the first received 8-bit byte with the general call address
(00H). If an equality is found, the appropriate status bits are set and
an interrupt is requested.
S
HIFT
R
EGISTER,
S
1
DAT
This 8-bit special function register contains a byte of serial data to
be transmitted or a byte which has just been received. Data in
S1DAT is always shifted from right to left; the first bit to be
transmitted is the MSB (bit 7) and, after a byte has been received,
the first bit of received data is located at the MSB of S1DAT. While
data is being shifted out, data on the bus is simultaneously being
shifted in; S1DAT always contains the last byte present on the bus.
Thus, in the event of lost arbitration, the transition from master
transmitter to slave receiver is made with the correct data in S1DAT.
