參數資料
型號： MCIMX281AVM4B
廠商： FREESCALE SEMICONDUCTOR INC
元件分類： 微控制器/微處理器
英文描述： 32-BIT, 454 MHz, RISC PROCESSOR, PBGA289
封裝： 14 X 14 MM, 0.80 MM PITCH, ROHS COMPLIANT, PLASTIC, MAPBGA-289
文件頁數： 2/72頁
文件大小： 915K
代理商： MCIMX281AVM4B
i.MX28 Applications Processors Data Sheet for Automotive Products, Rev. 1
10
Freescale Semiconductor
2.1
Special Signal Considerations
Special signal considerations are listed in Table 5. The package contact assignment is found in Section 4,
“Package Information and Contact Assignments.” Signal descriptions are provided in the reference
manual.
Table 5. Signal Considerations
Signal
Descriptions
PSWITCH
The pin is used for chip power on or recovery. VDDIO can be applied to PSWITCH through a
10 k
Ω resistor. This is necessary in order to enter the chip’s firmware recovery. The on-chip
circuitry prevents the actual voltage on the pin from exceeding acceptable levels.
VDDXTAL
This pin is an output of i.MX28. Should be coupled to ground with a 0.1 uF capacitor. User
should not supply external power to this pin.
BATTERY
This pin should be connected to the battery with minimal resistance. It provides charging current
to the battery.
See the “Power Supply” section of the reference manual for details.
DCDC_BATTERY
This pin is an input of i.MX28 that provides supply to the DCDC converter. It should be
connected to the battery with minimal resistance. See the “Power Supply” section of the
reference manual for details.
XTALI
XTALO
These analog pins are connected to an external 24 MHz crystal circuit. This crystal provides the
clock source for on-chip PLLs.
RTC_XTALO
RTC_XTALI
These analog pins are connected to an external 32.768/32.0 kHz crystal circuit. This crystal
provides clock source to the on-chip real-time counter circuits.
RESETN
This pin resets the chip if it is low. This pin is pulled up to VDDIO33 with an internal 10 kohm
resistor. No external pull up resistors are needed.
DEBUG
This pin is used for JTAG interface.
DEBUG=0: JTAG interface works for boundary scan.
DEBUG=1: JTAG interface works for ARM debugging.
TESTMODE
For Freescale factory use only. Must be externally connected to GND for normal operation.
相關PDF資料
PDF描述
MCP25020-I/P SPECIALTY MICROPROCESSOR CIRCUIT, PDIP14
MCP25050T-E/SL SPECIALTY MICROPROCESSOR CIRCUIT, PDSO14
MCP25055-I/SL SPECIALTY MICROPROCESSOR CIRCUIT, PDSO14
MCP2510T-E/P 2 CHANNEL(S), 1M bps, LOCAL AREA NETWORK CONTROLLER, PDIP18
MCZ33781EK SPECIALTY MICROPROCESSOR CIRCUIT, PDSO32
相關代理商/技術參數
參數描述
MCIMX283CVM4B 功能描述:處理器 - 專門應用 CATSKILLS REV 1.2 RoHS:否 制造商:Freescale Semiconductor 類型:Multimedia Applications 核心:ARM Cortex A9 處理器系列:i.MX6 數據總線寬度:32 bit 最大時鐘頻率:1 GHz 指令/數據緩存: 數據 RAM 大小:128 KB 數據 ROM 大小: 工作電源電壓: 最大工作溫度:+ 95 C 安裝風格:SMD/SMT 封裝 / 箱體:MAPBGA-432
MCIMX283CVM4BR2 功能描述:處理器 - 專門應用 Catskills Rev1.2 RoHS:否 制造商:Freescale Semiconductor 類型:Multimedia Applications 核心:ARM Cortex A9 處理器系列:i.MX6 數據總線寬度:32 bit 最大時鐘頻率:1 GHz 指令/數據緩存: 數據 RAM 大小:128 KB 數據 ROM 大小: 工作電源電壓: 最大工作溫度:+ 95 C 安裝風格:SMD/SMT 封裝 / 箱體:MAPBGA-432
MCIMX283DJM4A 制造商:Freescale Semiconductor 功能描述:CATSKILLS REV 1.1 - Trays 制造商:Freescale Semiconductor 功能描述:IC MCU 32BIT ROMLESS 289MAPBGA
MCIMX283DVM4B 功能描述:處理器 - 專門應用 CATSKILLS REV 1.2 RoHS:否 制造商:Freescale Semiconductor 類型:Multimedia Applications 核心:ARM Cortex A9 處理器系列:i.MX6 數據總線寬度:32 bit 最大時鐘頻率:1 GHz 指令/數據緩存: 數據 RAM 大小:128 KB 數據 ROM 大小: 工作電源電壓: 最大工作溫度:+ 95 C 安裝風格:SMD/SMT 封裝 / 箱體:MAPBGA-432
MCIMX285AJM4A 制造商:Freescale Semiconductor 功能描述:CATSKILLS REV 1.1 - Bulk
