GENERAL RELEASE SPECIFICATION
MC68HC05P9A
MEMORY
MOTOROLA
Rev. 2.0
2-3
2.1
ROM
The user ROM consists of 48 bytes of page zero ROM from $0020 to $004F, 2048
bytes of ROM from $0100 to $08FF, and 16 bytes of user vectors from $1FF0 to
$1FFF. The self-check ROM and vectors are located from $1F00 to $1FEF.
2.2
ROM Security Feature
A security feature has been incorporated into the MC68HC05P9A to help prevent
external reading of code in the ROM. Placing unique customer code at ROM
locations $0028-$002F aids in keeping customer developed software proprietary.
2.3
RAM
The user RAM consists of 128 bytes of a shared stack area. The stack begins at
address $00FF. The stack pointer can access 64 bytes of RAM in the range
$00FF to $00C0.
NOTE
Using the stack area for data storage or temporary work locations
requires care to prevent it from being overwritten due to stacking
from an interrupt or subroutine call.
