LTC4269-2
0
42692fb
applicaTions inForMaTion
Example (3) Time For Maximum Duty Cycle Clamp to
Reach Within X% of Target Value
Amaximumdutycycleclampof72%wascalculatedprevi-
ously in the section ‘Programming Maximum Duty Cycle
Clamp’. The programmed value used for SS_MAXDC(DC)
was 1.84V.
ThetimeforSS_MAXDCtochargefromitsminimumvalue
VSS(MIN) to within X% of SS_MAXDC(DC) is given by:
t(SS_MAXDC charge time within X% of target)
= t[(1 – (X/100) SS_MAXDC(DC)] – t(VSS(MIN))
For X = 2 and VSS(MIN) = 0.45V, t(0.98 1.84) – t(0.45)
= t(1.803) – t(0.45)
From previous calculations, t(0.45) = 7.3e–4s.
Using previous values for RT, RB and CSS,
t(1.803) = 2.63e–4 1e–7 (–1) ln(1 – 1.803/1.84)
= 2.63e–3 (–1) ln(0.02) = 1.03e–2 s
Hence the time for SS_MAXDC to charge from its mini-
mum reset threshold of 0.45V to within 2% of its target
value is given by:
t(1.803) – t(0.45) = 1.03e–2 – 7.3e–4 = 9.57e–3s
