0
APT30GP60B
Figure 22, Turn-on Switching Waveforms and Definitions
10 %
5 %
10%
t
d(on)
t
r
90%
5 %
Gate Voltage
Collector Voltage
Collector Current
Switching Energy
T
J
= 125 C
Figure 23, Turn-off Switching Waveforms and Definitions
T
J
= 125 C
Collector Current
Collector Voltage
Gate Voltage
90%
90%
t
f
t
d(off)
0
10%
Switching Energy
T0-247 Package Outline
15.49 (.610)
16.26 (.640)
5.38 (.212)
6.20 (.244)
6.15 (.242) BSC
4.50 (.177) Max.
19.81 (.780)
20.32 (.800)
20.80 (.819)
21.46 (.845)
1.65 (.065)
2.13 (.084)
1.01 (.040)
1.40 (.055)
3.50 (.138)
3.81 (.150)
2.87 (.113)
3.12 (.123)
4.69 (.185)
5.31 (.209)
1.49 (.059)
2.49 (.098)
2.21 (.087)
2.59 (.102)
0.40 (.016)
0.79 (.031)
C
Collector
Emitter
Gate
5.45 (.215) BSC
2-Plcs.
Dimensions in Millimeters and (Inches)
APT’s products are covered by one or more of U.S.patents 4,895,810 5,045,903 5,089,434 5,182,234 5,019,522
5,262,336 6,503,786 5,256,583 4,748,103 5,283,202 5,231,474 5,434,095 5,528,058 and foreign patents. US and Foreign patents pending. All Rights Reserved.
*DRIVER SAME TYPE AS D.U.T.
I
C
V
CLAMP
100uH
V
TEST
A
A
B
D.U.T.
DRIVER*
V
CE
Figure 24, E
ON1
Test Circuit
I
C
A
D.U.T.
APT15DF60
V
CE
Figure 21, Inductive Switching Test Circuit
V
CC
