- 您現在的位置：買賣IC網 > PDF目錄222673 > 5962F9671201VXC (INTERSIL CORP) Radiation Hardened Hex Inverter PDF資料下載
參數資料
| 型號： | 5962F9671201VXC |
| 廠商： | INTERSIL CORP |
| 元件分類： | 門電路 |
| 英文描述： | Radiation Hardened Hex Inverter |
| 中文描述： | ACT SERIES, HEX 1-INPUT INVERT GATE, CDFP14 |
| 封裝： | CERAMIC, DFP-14 |
| 文件頁數： | 9/23頁 |
| 文件大?。?/td> | 187K |
| 代理商： | 5962F9671201VXC |
STANDARD
MICROCIRCUIT DRAWING
SIZE
A
5962-96712
DEFENSE SUPPLY CENTER COLUMBUS
COLUMBUS, OHIO 43218-3990
REVISION LEVEL
D
SHEET
17
DSCC FORM 2234
APR 97
APPENDIX A
APPENDIX A FORMS A PART OF SMD 5962-96712
A.1 SCOPE
A.1.1 Scope. This appendix establishes minimum requirements for microcircuit die to be supplied under the Qualified
Manufacturers List (QML) Program. QML microcircuit die meeting the requirements of MIL-PRF-38535 and the manufacturers
approved QM plan for use in monolithic microcircuits, multi-chip modules (MCMs), hybrids, electronic modules, or devices using
chip and wire designs in accordance with MIL-PRF-38534 are specified herein. Two product assurance classes consisting of
military high reliability (device class Q) and space application (device Class V) are reflected in the Part or Identification Number
(PIN). When available a choice of Radiation Hardness Assurance (RHA) levels are reflected in the PIN.
A.1.2 PIN. The PIN is as shown in the following example:
5962
F
96712
02
V
9
A
Federal
stock class
designator
RHA
designator
(see A.2.1)
Device
type
(see A.2.2)
Device
class
designator
Die
code
Die
details
(see A.2.4)
\
/
(see A.2.3)
\/
Drawing number
A.1.2.1 RHA designator. Device classes Q and V RHA identified die shall meet the MIL-PRF-38535 specified RHA levels. A
dash (-) indicates a non-RHA die.
A.1.2.2 Device type(s). The device type(s) shall identify the circuit function as follows:
Device type
Generic number
Circuit function
02
ACTS04-02
Radiation hardened, SOS,
advanced CMOS, hex inverter,
TTL compatible inputs.
A.1.2.3 Device class designator.
Device class
Device requirements documentation
Q or V
Certification and qualification to the die requirements of MIL-PRF-38535.
