| 型號： | 5962F9671201VXC |
| 廠商： | INTERSIL CORP |
| 元件分類： | 門電路 |
| 英文描述： | Radiation Hardened Hex Inverter |
| 中文描述： | ACT SERIES, HEX 1-INPUT INVERT GATE, CDFP14 |
| 封裝： | CERAMIC, DFP-14 |
| 文件頁數： | 18/23頁 |
| 文件大小： | 187K |
| 代理商： | 5962F9671201VXC |
STANDARD
MICROCIRCUIT DRAWING
SIZE
A
5962-96712
DEFENSE SUPPLY CENTER COLUMBUS
COLUMBUS, OHIO 43218-3990
REVISION LEVEL
D
SHEET
4
DSCC FORM 2234
APR 97
2. APPLICABLE DOCUMENTS
2.1 Government specification, standards, and handbooks. The following specification, standards, and handbooks form a part
of this drawing to the extent specified herein. Unless otherwise specified, the issues of these documents are those cited in the
solicitation or contract.
DEPARTMENT OF DEFENSE SPECIFICATION
MIL-PRF-38535 - Integrated Circuits, Manufacturing, General Specification for.
DEPARTMENT OF DEFENSE STANDARDS
MIL-STD-883
-
Test Method Standard Microcircuits.
MIL-STD-1835 -
Interface Standard Electronic Component Case Outlines.
DEPARTMENT OF DEFENSE HANDBOOKS
MIL-HDBK-103 -
List of Standard Microcircuit Drawings.
MIL-HDBK-780 -
Standard Microcircuit Drawings.
(Copies of these documents are available online at http://assist.daps.dla.mil/quicksearch/ or http://assist.daps.dla.mil or from
the Standardization Document Order Desk, 700 Robbins Avenue, Building 4D, Philadelphia, PA 19111-5094.)
2.2 Non-Government publications. The following document(s) form a part of this document to the extent specified herein.
Unless otherwise specified, the issues of the documents are the issues of the documents cited in the solicitation or contract.
AMERICAN SOCIETY FOR TESTING AND MATERIALS (ASTM)
ASTM F1192- Standard Guide for the Measurement of Single Event Phenomena (SEP) Induced by Heavy Ion Irradiation
of Semiconductor Devices.
(Copies of this document is available online at http://www.astm.org/ or from ASTM International, P. O. Box C700,
100 Barr Harbor Drive, West Conshohocken, PA 19428-2959).
2.3 Order of precedence. In the event of a conflict between the text of this drawing and the references cited herein, the text of
this drawing takes precedence. Nothing in this document, however, supersedes applicable laws and regulations unless a
specific exemption has been obtained.
3. REQUIREMENTS
3.1 Item requirements. The individual item requirements for device classes Q and V shall be in accordance with
MIL-PRF-38535 and as specified herein or as modified in the device manufacturer's Quality Management (QM) plan. The
modification in the QM plan shall not affect the form, fit, or function as described herein. The individual item requirements for
device class M shall be in accordance with MIL-PRF-38535, appendix A for non-JAN class level B devices and as specified
herein.
3.1.1 Microcircuit die. For the requirements for microcircuit die, see appendix A to this document.
3.2 Design, construction, and physical dimensions. The design, construction, and physical dimensions shall be as specified in
MIL-PRF-38535 and herein for device classes Q and V or MIL-PRF-38535, appendix A and herein for device class M.
3.2.1 Case outlines. The case outlines shall be in accordance with 1.2.4 herein.
3.2.2 Terminal connections. The terminal connections shall be as specified on figure 1.
3.2.3 Truth table. The truth table shall be as specified on figure 2.
3.2.4 Logic diagram. The logic diagram shall be as specified on figure 3.
3.2.5 Switching waveforms and test circuit. The switching waveforms and test circuit shall be as specified on figure 4.
3.2.6 Irradiation test connections. The irradiation test connections shall be as specified in table III.
