XRT91L82
2.488/2.666 GBPS STS-48/STM-16 SONET/SDH TRANSCEIVER
PRELIMINARY
xr
REV. P1.0.5
5
REF2CLKP
REF2CLKN
LVPECL Diff
I
A11
B11
Reference Clock Input 2
This differential clock input reference is used for the transmit
clock multiplier unit (CMU) and clock data recovery (CDR) to
provide the necessary high-speed clock reference for this
device. Pin REFREQSEL[1:0] determines the value used as
the reference. See Pin REFREQSEL[1:0] for more details.
Internally terminated and biased.
REFREQSEL1
/ SCLK
LVTTL,
LVCMOS
I
D12
Reference Clock Frequency Select
Hardware Mode
REFREQSEL1 pin is used to select the fre-
quency of the REF1CLK and/or REF2CLK input to the CMU
and CDR.
N
OTE
:
Non-FEC rates require 155.52 MHz clock reference.
FEC rates require 166.63 MHz clock reference
This pin is provided with an internal pull-down.
Host Mode
This pin is functions as the microprocessor Serial
Clock Input.
REFREQSEL0
LVTTL,
LVCMOS
I
E12
Reference Clock Frequency Select
REFREQSEL0 pin is used to select the frequency of the
REF1CLK and/or REF2CLK input to the CMU and CDR.
N
OTE
:
Non-FEC rates require 155.52 MHz clock reference.
FEC rates require 166.63 MHz clock reference
This pin is provided with an internal pull-down.
COMMON CONTROL
N
AME
L
EVEL
T
YPE
P
IN
D
ESCRIPTION
REFREQSEL
[1:0]
CMU
REFERENCE
FREQUENCY
CDR
REFERENCE
FREQUENCY
00
155.52 MHz present on
REF1CLK
REF2CLK not used
155.52 MHz present on
REF1CLK
REF2CLK not used
01
155.52 MHz present on
REF1CLK
166.63 MHz present on
REF2CLK
10
166.63 MHz present on
REF2CLK
155.52 MHz present on
REF1CLK
11
166.63 MHz present on
REF2CLK
REF1CLK not used
166.63 MHz present on
REF2CLK
REF1CLK not used
REFREQSEL
[1:0]
CMU
REFERENCE
FREQUENCY
CDR
REFERENCE
FREQUENCY
00
155.52 MHz present on
REF1CLK
REF2CLK not used
155.52 MHz present on
REF1CLK
REF2CLK not used
01
155.52 MHz present on
REF1CLK
166.63 MHz present on
REF2CLK
10
166.63 MHz present on
REF2CLK
155.52 MHz present on
REF1CLK
11
166.63 MHz present on
REF2CLK
REF1CLK not used
166.63 MHz present on
REF2CLK
REF1CLK not used
