Data Sheet U15183EJ2V0DS
16
PD703078Y, 703079Y, 70F3079Y
Table 2-1. Types of Pin I/O Circuits and Connection of Unused Pins (2/2)
Pin
Alternate Function
I/O Circuit Type
I/O Buffer
Power Supply
Recommended Connection of Unused Pins
P100
KR0/TO7
P101
KR1/TI70
P102
KR2/TI00
P103
KR3/TI01
P104
KR4/TO0
P105
KR5/TI10
P106
KR6/TI11
P107
KR7/TO1
8-A
PORTVDD
Input:
Individually connect to PORTVDD or
PORTGND via a resistor.
Output:
Leave open.
P110
WAIT
P111 to P113
5
P114
CANTX1
5
P115
CANRX1
8
P116
CANTX2
Note 1
5
P117
CANRX2
Note 1
8
PORTVDD
Input:
Individually connect to PORTVDD or
PORTGND via a resistor.
Output:
Leave open.
CLKOUT
4PORTVDD
Leave open.
RESET
2PORTVDD
X1
X2
XT1
Connect to GND0 to GND2 via a resistor.
XT2
Leave open.
VPP
Note 2
Connect to GND0 to GND2.
IC
Note 3
Connect directly to GND0 to GND2.
CPUREG
VDD0
GND0 to
GND2
ADCVDD
ADCGND
PORTVDD
PORTGND
Notes 1.
PD703079Y, 70F3079Y only
2.
PD70F3079Y only
3.
PD703078Y, 703079Y only
