Preliminary Data Sheet M17506EJ1V1DS
32
μ
PD46128953-X
5. 3 Read / Write Command Loading
A command (read/write) is loaded in the same timing as an address (refer to
6.2 Address Latching
). If /WE = HIGH
at that time, a read operation is started; if /WE = LOW, a write operation is started. Figure 5-5 shows a read operation
and Figure 5-6 shows a write operation. If /WE = LOW in the cycle next to that in which an address is loaded as shown in
Figure 5-7
, a write operation is not recognized. The operation in Figure 5-7 is a read operation.
Figure 5-5. Command Loading Timing 1
T0
T1
T2
H
t
CHV
t
CSV
t
CES
t
WES
t
WEH
t
CHV
CLK (Input)
/CE1 (Input)
/OE (Input)
/WE (Input)
/ADV (Input)
Command Input
Remarks 1.
Figure 5-5 shows a read operation
2.
Refer to
6. Electrical Specifications
,
7. Timing Charts
in detail of AC specification.
