參數資料
| 型號： | SI5374B-A-GL |
| 廠商： | Silicon Laboratories Inc |
| 文件頁數： | 1/69頁 |
| 文件大小： | 0K |
| 描述： | IC CLK GEN/JITTER ATTEN 80LBGA |
| 標準包裝： | 240 |
| 系列： | DSPLL® |
| 類型： | 時鐘發生器，漂移衰減器 |
| PLL： | 是 |
| 輸入： | 時鐘 |
| 輸出： | CML，CMOS，LVDS，LVPECL |
| 電路數： | 1 |
| 比率 - 輸入:輸出： | 8:8 |
| 差分 - 輸入:輸出： | 是/是 |
| 頻率 - 最大： | 808MHz |
| 除法器/乘法器： | 是/是 |
| 電源電壓： | 1.71 V ~ 2.75 V |
| 工作溫度： | -40°C ~ 85°C |
| 安裝類型： | 表面貼裝 |
| 封裝/外殼： | 80-LBGA |
| 供應商設備封裝： | 80-BGA（10x10） |
| 包裝： | 托盤 |
| 其它名稱： | 336-2046 |
當前第1頁第2頁第3頁第4頁第5頁第6頁第7頁第8頁第9頁第10頁第11頁第12頁第13頁第14頁第15頁第16頁第17頁第18頁第19頁第20頁第21頁第22頁第23頁第24頁第25頁第26頁第27頁第28頁第29頁第30頁第31頁第32頁第33頁第34頁第35頁第36頁第37頁第38頁第39頁第40頁第41頁第42頁第43頁第44頁第45頁第46頁第47頁第48頁第49頁第50頁第51頁第52頁第53頁第54頁第55頁第56頁第57頁第58頁第59頁第60頁第61頁第62頁第63頁第64頁第65頁第66頁第67頁第68頁第69頁
Rev. 1.1 1/14
Copyright 2014 by Silicon Laboratories
Si5374
4-PLL A NY-F REQUENCY P RECISION C LOCK
M ULTIPLIER/J ITTER A TTENUATOR
Features
Applications
Description
The Si5374 is a highly-integrated, 4-PLL, jitter-attenuating precision clock
multiplier for applications requiring sub-1 ps jitter performance. Each of the
DSPLL clock multiplier engines accepts two input clocks ranging from 2 kHz to
710 MHz and generates two independent synchronous output clocks ranging
from 2 kHz to 808 MHz. The device provides virtually any frequency translation
combination across this operating range. For asynchronous, free-running clock
generation applications, the Si5374’s reference oscillator can be used as a clock
source for any of the four DSPLLs. The Si5374 input clock frequency and clock
multiplication ratio are programmable through an I2C interface. The Si5374 is
based on Silicon Laboratories’ third-generation DSPLL technology, which
provides any-frequency synthesis and jitter attenuation in a highly-integrated
PLL solution that eliminates the need for external VCXO and loop filter
components. Each DSPLL loop bandwidth is digitally-programmable, providing
jitter performance optimization at the application level. The device operates from
a single 1.8 or 2.5 V supply with on-chip voltage regulators with excellent PSRR.
The Si5374 is ideal for providing clock multiplication and jitter attenuation in
high-port-count optical line cards requiring independent timing domains.
Highly-integrated, 4 PLL clock
multiplier/jitter attenuator
Four independent DSPLLs support
any-frequency synthesis and jitter
attenuation
8 inputs/8 outputs
Each DSPLL can generate any
frequency from 2 kHz to 808 MHz
from a 2 kHz to 710 MHz input
Ultra-low jitter clock outputs:
350 fs rms (12 kHz–20 MHz) and
410 fs rms (50 kHz–80 MHz) typical
Meets ITU-T G.8251 and Telcordia
GR-253-CORE OC-192 jitter
specifications
Supports all ITU G.709 and any
custom FEC ratios (239/237,
255/238, 255/237, 255/236,
253/226)
Integrated loop filter with
programmable bandwidth
Simultaneous free-run and
synchronous operation
Automatic/manual hitless input clock
switching
Selectable output clock signal
format (LVPECL, LVDS, CML,
CMOS)
LOL and interrupt alarm outputs
I2C programmable
Single 1.8 V ±5% or 2.5 V ±10%
operation with high PSRR on-chip
voltage regulator
10x10 mm PBGA
High-density, any-port, any-protocol,
any-frequency line cards
ITU-T G.709 OTN custom FEC
10/40/100G
OC-48/192, STM-16/64
1/2/4/8/10G Fibre Channel
GbE/10 GbE Synchronous Ethernet
Carrier Ethernet, multi-service
switches and routers
MSPP, ROADM, P-OTS,
muxponders
Ordering Information:
See page 63.
